7Semi IMU BMI270 Accelerometer and Gyroscope Breakout STEMMA QT / Qwiic

7Semi

1 review Write a Review
SKU:
004-ES-12135
Manufacturer Part Number:
ES-12135
₹761.10 inc. GST
₹645.00 ex. GST
The 7Semi IMU BMI270 Breakout is a compact and easy-to-use sensor module that combines a 3-axis accelerometer and gyroscope in a single package. This makes it ideal for projects that require precise motion and orientation sensing. View full description
₹761.10 inc. GST
₹645.00 ex. GST
11 people looking at this.

Description

The ES-12135 breakout board integrates BMI270 which is a member of Bosch Sensortec's BMI260 family of IMUS, targeting fast and accurate inertial sensing in wearable applications. BMI270 features Bosch's automotive-proven gyroscope technology with an improved accelerometer.

BMI270 features the industry's first self-calibrating gyroscope using motionless CRT (Component ReTrimming) functionality to compensate MEMS typical soldering drifts, ensuring post-soldering sensitivity errors down to +- 0.4%. BM1270 includes intuitive gesture, context and activity recognition with an integrated plug-and-play step counter/detector, which is optimized for accurate step counting in wrist-worn devices. The IMU is also well suited for other types of wearable devices, such as hearables, smart clothes, smart shoes, smart glasses and ankle bands.

STEMMA QT / Qwiic 4-pin 1mm Pitch White Female Connector Cable 150mm Long - Both Side can be purchased seperately.

Key Features
  • 3.3v and 5v voltage operation
  • 16-bit 3-axis accelerometer with +- 2g/4g/8g/16g range
  • 16-bit 3-axis gyroscope with +- 125dps/250dps/500dps/1000dps/2000dps range
  • Significant motion/Any motion/Motion detect/No motion/Stationary detect/Wrist wear wakeup/Wrist worn step counter and detector/Activity change recognition/Push arm down/Pivot up/Wrist jiggle/Flick in /out

The BMI270 Accelerometer and Gyroscope Breakout is an advanced sensor module that combines an accelerometer and a gyroscope to measure motion and orientation. It can operate with both 3.3V and 5V power supplies, making it easy to integrate into a wide range of systems.

The accelerometer in the BMI270 can measure linear acceleration in three axes with a range of +/- 2g, +/- 4g, +/- 8g, or +/- 16g. Meanwhile, the gyroscope can measure angular velocity in three axes with a range of +/- 125dps, +/- 250dps, +/- 500dps, +/- 1000dps, or +/- 2000dps. The module also features advanced motion detection capabilities, including significant motion, any motion, no motion, stationary detect, wrist wear wakeup, wrist worn step counter and detector, activity change recognition, push arm down, pivot up, wrist jiggle, and flick in/out.

The BMI270 Accelerometer and Gyroscope Breakout is highly precise and accurate, making it ideal for applications that require accurate motion and orientation sensing, such as robotics, virtual reality, and motion tracking. Its advanced motion detection capabilities also make it suitable for applications that require advanced activity recognition and wearables.

The IMU BMI270 Accelerometer and Gyroscope Breakout is a powerful and versatile sensor module that can provide valuable data on motion and orientation in a wide range of applications.

Resources

BMI270 Accelerometer and Gyroscope Breakout Dimensions

BMI270 Accelerometer and Gyroscope Breakout Pinout

BMI270 Breakout Arduino Connection

An Accelerometer and Gyroscope Breakout is a sensor module that combines two important sensors for measuring motion and orientation - an accelerometer and a gyroscope. The accelerometer measures linear acceleration, while the gyroscope measures angular velocity. Together, they provide a complete picture of an object's movement in three-dimensional space.

The Accelerometer and Gyroscope Breakout is typically used in applications that require precise measurement of motion and orientation, such as robotics, virtual reality systems, and motion tracking. It can also be used in mobile devices to enable features such as screen rotation and gesture recognition.

The module typically communicates with a microcontroller or other device through an I2C or SPI interface, and can be powered by a 3.3V or 5V power supply. Its high accuracy and sensitivity make it an essential component in many advanced sensing and control systems. Overall, an Accelerometer and Gyroscope Breakout is a powerful tool for measuring motion and orientation in a wide range of applications.

Technical Specifications

Brand:
7Semi
