R01 IP67 Waterproof Small Laser Ranging Sensor 2~400cm

DYP

No reviews yet Write a Review
SKU:
514-DYP-R01UW-V1.0
MPN:
DYP-R01UW-V1.0
DYP Sensor R01 IP67 waterproof small laser ranging sensor for 2 cm to 400 cm robot obstacle-avoidance, access-control, and object-presence detection
Quantity
Unit Price (ex. GST)
1 - 9
₹ 1,012.83
10 - 49
₹ 962.19
50 or above
₹ 911.55
DYP Sensor R01 IP67 waterproof DYP-R01 small laser ranging sensor with 2 cm to 400 cm range, millimetre resolution, 30 ms response, UART, IIC, and switching outputs for robot, access-control, and object detection. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹1,195.14 inc. GST
₹1,012.83 ex. GST
9 people looking at this.

Technical Specifications

Brand:
DYP
Product Type:
Laser Ranging Sensor
Series:
R01
Sensing Method:
Laser
Probe Type:
Closed Waterproof Bistatic Probe
Waterproof Rating:
IP67
Measuring Range:
2 cm - 400 cm
Blind Zone:
2 cm
TTL-Level Switching Output:
3.3 V
Resolution:
Millimetre Level
Output Interface Options:
UART Automatic, UART Controlled, Switching Output, TTL-Level Switching, IIC
Working Voltage:
3.3 V - 5 V DC
Structure Type:
Reflective
Working Current:
Lower Than 8 mA At 12 V DC
Flat Object Measurement Accuracy:
1 Plus S x 0.5%
Standby Current:
Lower Than 10 uA
Measurement Accuracy:
+- 1 Plus S x 0.3% cm
Operating Temperature:
-15 C ~ +60 C
Detection Angle:
~ 19 deg
Installation Design:
Circular Exposed Sensor Area
Default Baud-Rate:
115200
Applications:
Robot Obstacle-Avoidance, Human-Induction, Horizontal-Ranging, Object-Presence Sensing

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources

DYP Sensor R01 IP67 Waterproof Small Laser Ranging Sensor For 2 cm To 400 cm Distance Detection And Object-Presence Sensing

The DYP Sensor R01 is a compact IP67 waterproof laser ranging sensor designed for reliable indoor distance measurement from 2 cm to 400 cm. It offers millimetre-level resolution, fast response, and stable data output, making it well-suited for robot obstacle-avoidance, automatic-control systems, human-induction sensing, object-proximity detection, and horizontal-ranging applications.

This small laser ranging sensor uses a reflective detection structure and supports multiple output options, including UART automatic output, UART controlled output, switching output, TTL-level switching output, and IIC output. The 3.3 V to 5 V working-voltage range allows easy integration with common embedded controllers, development boards, and compact automation devices.

The R01 module is built with a circular exposed sensor area for simple installation and strong installation-adaptability. Its IP67 waterproof structure, small blind-area, wide working-temperature range, and baud-rate modification support make it suitable for product designs that need compact size, stable ranging, and flexible communication interfaces.

Key Features

  • IP67 Waterproof Design: Built for dust-prone, splash-prone, and moisture-exposed installations.
  • Small Blind-Area: Standard 2 cm blind-area supports close-range detection.
  • Wide Ranging Distance: Measures from 2 cm to 400 cm for short-to-medium range sensing.
  • Millimetre-Level Resolution: Provides fine distance feedback for precision-ranging applications.
  • Fast Ranging Response: Typical data output time is 30 ms for quick detection updates.
  • Multiple Output Modes: Supports UART automatic output, UART controlled output, switching output, TTL-level switching output, and IIC output.
  • Baud-Rate Modification: Default baud-rate is 115200 and can be changed to 4800, 9600, 14400, 19200, 38400, 57600, and 76800.
  • Address Modification Support: Useful for multi-sensor systems and address-based communication designs.
  • Strong Installation Adaptability: Circular exposed sensor area enables simple, stable, and reliable mounting.
  • Wide Working Temperature: Operates from -25 deg C to +65 deg C for varied application environments.
  • Stable Data Measurement: Designed for consistent ranging performance in embedded and industrial use.

Applications

  • Robot obstacle-avoidance
  • Automatic-control systems
  • Human-induction sensing
  • High-speed AF applications
  • Horizontal-ranging systems
  • Object-proximity detection
  • Object-presence awareness
  • Access-control detection
  • Compact automation equipment
  • Waterproof distance-sensing devices
