Full-Duplex TTL-to-RS232 Interface Base with MAX232 and 12V Power Input
The M5Stack A136 Atomic RS232 Base is a compact serial communication expansion base designed for M5Stack ATOM-series controllers. It integrates a MAX232 level-conversion IC to provide bidirectional conversion between the ATOM controller’s TTL UART signals and standard RS232 signal levels. This allows ATOM-based systems to communicate with industrial instruments, computers, controllers, serial peripherals, and other equipment that uses an RS232 interface.
The base also incorporates an AOZ1282CI DC-DC step-down regulator, allowing an external 12V power source to supply the connected ATOM controller through the expansion base. Full-duplex communication supports simultaneous transmit and receive operation, while the external 4-pin terminal simplifies connection to RS232 equipment and external power. The A136 package includes the RS232 base only and does not include an Atom-Lite controller.
Key Features
- Level Conversion: MAX232 bidirectional TTL-to-RS232 level converter
- Communication: Full-duplex serial transmission and reception
- ATOM Compatibility: Supports Atom-Matrix, Atom-Lite, ATOMS3, and AtomS3-Lite
- Power Conversion: Integrated AOZ1282CI DC-DC step-down regulator
- External Power: Supports powering the connected ATOM from an external 12V supply
- UART Interface: Uses ATOM UART TX and RX connections
- External Connection: 4-pin 3.96 mm terminal interface
- Compact Design: 24 × 48 × 18 mm form factor
- Enclosure: Polycarbonate housing
- Development Support: Arduino, UiFlow1, UiFlow2, and EasyLoader
- Controller Not Included: A136 is supplied without Atom-Lite
Applications
- RS232 serial communication
- Industrial control nodes
- Embedded equipment interfacing
- ATOM-based serial terminals
- Industrial instrumentation
- Legacy serial-device integration
- Equipment configuration interfaces
- Data-acquisition systems
- Automation controllers
- Point-to-point serial communication
- IoT gateway development
- MCU-to-RS232 interfacing
Model Size
Package Includes:
- 1 × Atomic RS232 Base
- 1 × HT3.96-4P
