Fermion: BMP280 Digital Pressure Sensor Breakout

DFRobot

No reviews yet Write a Review
SKU:
147-SEN0372
MPN:
SEN0372
Fermion BMP280 digital pressure sensor breakout with temperature sensing and I2C communication interface
Fermion BMP280 digital pressure sensor breakout with high-accuracy pressure and temperature measurement, I2C communication, low power consumption, and altitude sensing capability. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹656.08 inc. GST
₹556.00 ex. GST
14 people looking at this.

Technical Specifications

Brand:
DFRobot
Operating Voltage:
3.3V-5.5V
Communication Interface:
I2C(5V compatible)
Default I2C Address:
0x76
Pressure Measuring Range:
300~1100hPa
Relative Accuracy:
+-0.12hPa（+-1m）
Absolute Accuracy:
+-1hPa（+-8.33m）
Temperature Measuring Range:
0~65C
Temperature Measuring Accuracy:
0.01C
Dimension:
18x11.5mm
Mounting Hole Position:
13mm
Mounting Hole Size:
Inner diameter 2mm/outer diameter 3.7mm

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources

Digital Barometric Pressure And Temperature Sensor Breakout With High Accuracy I2C Interface


The Fermion BMP280 Digital Pressure Sensor Breakout is a compact environmental sensing module designed for accurate barometric pressure, temperature, altitude, and elevation measurements. Based on Bosch's proven piezo-resistive pressure sensing technology, the BMP280 delivers excellent accuracy, linearity, electromagnetic compatibility, and long-term stability. Its miniature footprint and low power consumption make it an ideal solution for portable devices, IoT systems, weather stations, navigation equipment, and battery-powered applications.

The sensor supports I2C communication, allowing seamless integration with Arduino, ESP32, Raspberry Pi, STM32, and other microcontroller platforms. In addition to measuring atmospheric pressure and temperature, the BMP280 can be used to calculate altitude and relative floor height based on changes in barometric pressure. This capability makes it particularly useful for indoor navigation, drone altitude measurement, GPS enhancement, environmental monitoring, and motion sensing applications. Multiple operating modes provide flexibility in balancing power consumption, measurement resolution, and filtering performance.

Key Features

  • BMP280 Sensor IC: Bosch high-accuracy digital pressure sensor.
  • Pressure and Temperature Measurement: Simultaneous environmental monitoring.
  • High Measurement Accuracy: Reliable pressure and temperature sensing.
  • Piezo-Resistive Technology: Proven Bosch sensing technology.
  • I2C Communication Interface: Easy integration with microcontrollers.
  • Altitude Measurement Capability: Calculates altitude from barometric pressure.
  • Relative Height Detection: Suitable for floor-level and elevation measurements.
  • Low Power Consumption: Ideal for battery-powered devices.
  • Compact Breakout Design: Easy integration into embedded systems.
  • High EMC Robustness: Stable operation in electrically noisy environments.
  • Excellent Long-Term Stability: Reliable performance over extended periods.
  • Flexible Operating Modes: Optimized balance between power and performance.
Applications

  • Weather monitoring stations
  • Altitude measurement systems
  • Indoor navigation devices
  • GPS enhancement systems
  • Drone altitude control
  • Environmental monitoring
  • IoT sensor nodes
  • Smart home automation
  • Portable weather instruments
  • Data logging systems
  • Robotics projects
  • Wearable electronics

Package Contents

  • BMP280 Digital pressure sensor module(V1.0) x1
  • 2.54 Single Row 4PIN Connector x1
