10 DOF IMU Sensor Module With Accelerometer, Gyroscope, Magnetometer, and Barometric Pressure Sensor

The Fermion 10 DOF IMU Sensor Breakout is a compact and cost-effective inertial measurement unit designed for advanced motion sensing, navigation, orientation tracking, and environmental monitoring applications. The module integrates four high-performance sensors, including the ADXL345 3-axis accelerometer, ITG3205 3-axis gyroscope, VCM5883L 3-axis magnetometer, and BMP280 barometric pressure sensor. Together, these sensors provide a complete 10 Degrees of Freedom sensing solution for accurately measuring motion, rotation, direction, altitude, and atmospheric pressure.

Designed for robotics, drones, navigation systems, balancing platforms, and human-computer interaction applications, the module delivers stable and accurate sensor data in a compact form factor. An onboard low-noise LDO regulator supports a wide input voltage range of 3V to 8V, making the module directly compatible with Arduino and other popular development platforms. The integrated mounting holes simplify installation while ensuring reliable operation in mobile and embedded systems.

Key Features

• 10 DOF Motion Sensing: Combines acceleration, rotation, heading, and pressure measurements.
• ADXL345 Accelerometer: 3-axis acceleration sensing.
• ITG3205 Gyroscope: 3-axis angular velocity measurement.
• VCM5883L Magnetometer: 3-axis magnetic field and compass sensing.
• BMP280 Barometric Sensor: Atmospheric pressure and altitude measurement.
• Integrated IMU Solution: Multiple sensors combined on a single module.
• Wide Input Voltage Range: Supports 3V to 8V power input.
• Low Noise LDO Regulator: Stable power supply for improved measurement accuracy.
• Compact Breakout Design: Suitable for embedded and portable applications.
• Arduino Compatible: Easy integration with Arduino and other microcontrollers.
• Mounting Holes Included: Simplifies installation and mechanical stability.
• High Accuracy Sensor Data: Suitable for navigation and motion control systems.

Applications

• Robotics and automation
• Drone flight control systems
• Self-balancing robots
• Navigation systems
• Human-computer interaction devices
• Motion tracking applications
• Electronic compass systems
• Altitude measurement
• Wearable electronics
• Autonomous vehicles
• Educational robotics projects
• Industrial motion monitoring

Specifications

FAQs:

Q: What sensors are included in the Fermion 10 DOF IMU Sensor?

A: The Fermion 10 DOF IMU Sensor includes the following sensors:

• ADXL345 accelerometer
• ITG3205 gyroscope
• HMC5883L magnetometer
• BMP280 barometric pressure sensor

Q: What is the interface used to communicate with the Fermion 10 DOF IMU Sensor?

A: The Fermion 10 DOF IMU Sensor uses the I2C interface to communicate with microcontrollers like Arduino.

Q: What is the power supply range for the Fermion 10 DOF IMU Sensor?

A: The Fermion 10 DOF IMU Sensor can be powered with a voltage range of 3 to 8 volts. It has an onboard LDO regulator for stable operation.

Q: What are the typical applications of the Fermion 10 DOF IMU Sensor?

A: The Fermion 10 DOF IMU Sensor is suitable for various applications, including:

• Robotics
• Navigation and motion tracking
• UAVs and drones
• Wearable electronics
• Tilt sensing and orientation detection
• Environmental monitoring

Q: Is the Fermion 10 DOF IMU Sensor compatible with Arduino?

A: Yes, the Fermion 10 DOF IMU Sensor is compatible with Arduino boards. DFRobot provides libraries and example code to facilitate easy integration with Arduino projects.
