Compact 9-Axis Absolute Orientation Sensor Module for Robotics and Motion Tracking
The 7Semi BNO055 9-Axis Absolute Orientation Sensor Micro Breakout is a compact motion-sensing module designed for systems that need accurate position and movement data in a small footprint. Built around the Bosch BNO055 smart sensor, it combines a 3-axis accelerometer, 3-axis gyroscope, and 3-axis magnetometer on a single board. Its onboard sensor-fusion processor delivers direct orientation data, which helps reduce controller-side processing and speeds up development.
This breakout board is well-suited for robotics, drones, wearable devices, motion-tracking systems, balancing platforms, and embedded automation projects. With support for I2C and UART communication, it is easy to integrate into a wide range of controllers and compact electronic designs. The small 13 x 9 x 4.7 mm form factor also makes it suitable for space-constrained applications where reliable orientation sensing is important.
Features
- 9-Axis Motion Sensing: Combines accelerometer, gyroscope, and magnetometer functions in 1 compact module.
- Built-In Sensor Fusion: Processes motion data internally and provides ready-to-use orientation output.
- Direct Motion Data Output: Delivers angles, rotation, and motion-related data without complex external calculations.
- Multi-Interface Support: Supports I2C and UART for flexible system integration.
- Compact Micro Breakout: Fits easily into embedded and portable device designs.
- Development-Friendly Design: Helps reduce setup time and simplifies motion-sensing implementation.
- Application Ready: Suitable for robotics, drones, wearables, navigation, and tracking systems.
7Semi BNO055 9-Axis Absolute Orientation Sensor Micro Breakout Applications
