Technical Specifications
Brand:
onsemi
Case/Package:
SOIC
Contact Plating:
Tin
Mount:
Surface Mount
Number of Pins:
8
Number of Terminals:
8
Current Rating:
100 mA
Dropout Voltage:
1.7 V
Max Input Voltage:
20 V
Max Junction Temperature (Tj):
125 C
Max Operating Temperature:
125 C
Max Output Current:
100 mA
Max Supply Voltage:
30 V
Min Input Voltage:
7 V
Min Operating Temperature:
0 C
Min Output Voltage:
5 V
Min Supply Voltage:
6.7 V
Nominal Output Voltage:
5 V
Nominal Supply Current:
3 mA
Number of Channels:
1
Number of Circuits:
1
Number of Outputs:
1
Number of Regulators:
1
Output Current:
100 mA
Output Type:
Fixed
Output Voltage:
5 V
Polarity:
Positive
Power Supply Rejection Ratio (PSRR):
49 dB
Voltage Tolerance:
4 %
Height:
1.75 mm
Height - Seated (Max):
1.75 mm
Length:
4.9 mm
Terminal Pitch:
1.27 mm
Width:
3.9 mm
