Versatile ATOM DIY Expansion Kit With Pin Breakout, HAT Adapter And Flexible Mounting Accessories
The M5Stack A086 Atom Mate is a DIY expansion kit designed for M5Stack Atom-Matrix and Atom-Lite controllers. It combines 3 practical expansion accessories - AtomPin, AtomHat, and AtomMount - to support circuit prototyping, breadboard development, M5StickC HAT integration, and mechanical mounting. The kit provides a convenient way to expand ATOM-series controllers without requiring users to design separate adapter hardware for common development setups.
AtomPin breaks out the bottom pins of an ATOM controller and uses a dedicated bracket that secures the controller without blocking pin access. Its perforated edges can be broken away as required for breadboard-based circuit building. AtomHat enables compatible M5StickC HAT accessories to be used with ATOM controllers, helping reuse existing hardware. AtomMount provides a simple mounting solution for attaching an ATOM controller to compatible building-block structures using a single screw, making the kit well-suited for DIY electronics, educational projects, and rapid hardware prototyping.
Key Features
- ATOM Compatibility: Designed for use with M5Stack Atom-Matrix and Atom-Lite controllers
- 3-Part Expansion Kit: Includes AtomPin, AtomHat, and AtomMount accessories for different development requirements
- Pin Breakout Support: AtomPin extends the bottom ATOM pins for easier circuit access and prototyping
- Breadboard Friendly: Perforated AtomPin design allows sections to be removed as required for breadboard integration
- HAT Compatibility: AtomHat allows compatible M5StickC HAT accessories to be used with supported ATOM controllers
- Flexible Mounting: AtomMount enables easy attachment of ATOM controllers to compatible building-block structures
- Compact Construction: Accessories maintain the small ATOM-series form factor for space-constrained projects
- DIY Focused: Supports multiple prototyping, adapter, and mechanical-integration methods
- Accessory Hardware Included: Supplied with pin headers, mounting screws, and a hex key for assembly
- PC Construction: Plastic components use PC material for lightweight mechanical support
Applications
- Experimental breadboard circuits
- ATOM controller prototyping
- M5StickC HAT adapter projects
- Embedded-system development
- DIY electronics projects
- Sensor and peripheral integration
- Building-block based projects
- Educational electronics
- Rapid hardware prototyping
- Custom ATOM expansion projects
- Mechanical mounting experiments
Model Size
Package Includes:
- 1 x AtomPin bracket
- 1 x AtomPin blank board
- 1 x AtomHat
- 1 x AtomMount
- 5 x 2.54-5P pin headers
- 1 x 2.54-4P pin header
- 1 x Hex key
- 1 x M2*6 cup head machine screw
- 1 x M2*8 cup head machine screw
