G6D-1A-ASI DC5 - 5V 5A 1FormA High Power Relay Through Hole 17.3x6.4mm

Omron Electronics

No reviews yet Write a Review
SKU:
169-G6D-1A-ASI-DC5
MPN:
G6D-1A-ASI DC5
G6D 5V 5A SPST normally open ultra slim high power relay through hole 17.3x6.4mm PCB relay for embedded systems
Quantity
Unit Price (ex. GST)
1 - 9
₹ 183.31
10 - 99
₹ 174.14
100 or above
₹ 164.98
5V 5A SPST (1 Form A) ultra-slim G6D relay with through-hole mounting. Ideal for microcontroller projects, automation, and compact PCB switching. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹216.31 inc. GST
₹183.31 ex. GST

Technical Specifications

Brand:
Omron Electronics
Package:
Through Hole
Contact Material:
Silver Alloy
Coil Voltage:
5V
Number of Pins:
4
Operating Temperature:
-25 C~+70 C
Release Time:
5ms
Operate Time:
10ms
Switching Current(Max):
5A
Contact Form:
1 Set Normally Open: 1A (SPST NO)
Size:
17.3x6.4mm
Coil Resistance:
125Ohm
Contact Resistance:
100mOhm

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:
Datasheet

5V 5A SPST (1 Form A Normally Open) Through Hole Relay for Compact PCB and Low-Voltage Control Applications

The G6D 5V 5A 1 Form A high power relay is a miniature electromechanical relay designed for efficient low-voltage switching in compact electronic systems. Operating with a 5V DC coil, this relay supports up to 5A switching capacity and features an SPST (Normally Open) configuration, making it ideal for simple ON/OFF control in microcontroller-based applications such as Arduino, ESP32, PLC outputs, and embedded control boards. Its ultra-slim footprint (~17.3x6.4mm) enables high-density PCB layouts without sacrificing performance.

Engineered for reliability and space efficiency, the G6D series offers fully sealed construction, strong dielectric strength, and stable switching characteristics. It supports switching up to 250V AC or 30V DC, with low contact resistance (~100mΩ) and fast response (~10ms operate, ~5ms release), ensuring dependable operation in automation, instrumentation, and signal control systems.

Key Features

  • 5A Switching Capacity: Suitable for control and moderate load switching
  • 5V DC Coil Voltage: Direct compatibility with microcontrollers
  • SPST (1 Form A): Normally Open configuration for simple switching
  • Ultra-Slim Design: ~17.3mmx6.4mm footprint for compact PCBs
  • Through Hole Mounting: Reliable and easy PCB integration
  • Fully Sealed Construction: Protection against dust and flux
  • Fast Switching Speed: ~10ms operate, ~5ms release
  • High Insulation Strength: ~3kV dielectric with 6kV surge withstand
  • Durable Contacts: Silver alloy for long operational life
  • Low Power Switching: Ideal for signal and control circuits
