G6D-1A-ASI DC24 - 24V 5A 1FormA High Power Relay Through Hole 17.3x6.4mm

Omron Electronics

No reviews yet Write a Review
SKU:
169-G6D-1A-ASI-DC24
MPN:
G6D-1A-ASI DC24
G6D 24V 5A SPST normally open ultra slim high power relay through hole 17.3x6.4mm PCB relay for compact electronics
Quantity
Unit Price (ex. GST)
1 - 9
₹ 162.62
10 - 99
₹ 154.49
100 or above
₹ 146.36
24V 5A SPST (1 Form A) ultra-slim G6D relay with through-hole mounting. Ideal for compact PCB designs, automation, and control applications. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹191.89 inc. GST
₹162.62 ex. GST
10 people looking at this.

Technical Specifications

Brand:
Omron Electronics
Package:
Through Hole
Contact Material:
Silver Alloy (Cd-Free)
Coil Voltage:
24V
Number of Pins:
3
Operating Temperature:
-25 C~+70 C
Release Time:
5ms
Operate Time:
10ms
Switching Current(Max):
5A
Contact Form:
1 Set Normally Open: 1A (SPST NO)
Size:
17.3x6.4mm
Coil Resistance:
2.88kOhm
Contact Resistance:
100mOhm

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:
Datasheet

24V 5A SPST (1 Form A Normally Open) Through Hole Relay for Compact PCB Switching Applications

The G6D 24V 5A 1 Form A high power relay is a compact and efficient electromechanical relay designed for space-constrained PCB applications. Operating with a 24V DC coil, it supports up to 5A switching capacity and features an SPST (Normally Open) configuration, making it suitable for simple ON/OFF control in automation systems, control circuits, and embedded electronics. Its miniature footprint (~17.3x6.4mm) allows easy integration into densely packed circuit boards without compromising switching performance.

Engineered for precision and reliability, the G6D series offers high dielectric strength, stable switching, and durable contact performance. With support for up to 250V AC / 30V DC switching and compact through-hole mounting, it is ideal for signal control, PLC interfaces, instrumentation, and low-to-medium power switching applications. The relay delivers dependable operation with efficient coil performance and long service life in industrial and commercial environments.

Key Features

  • 5A Switching Capacity: Suitable for control and moderate load switching
  • 24V DC Coil Voltage: Ideal for industrial and embedded systems
  • SPST (1 Form A): Normally Open configuration for simple switching
  • Ultra-Slim Design: ~17.3mmx6.4mm footprint
  • Through Hole Mounting: Reliable PCB integration
  • Compact PCB Relay: Ideal for high-density circuit layouts
  • High Dielectric Strength: Ensures safe operation
  • Durable Contacts: Silver alloy contacts for stable performance
  • Low Power Operation: Efficient coil design
