Fermion: Multi-function Environmental Board ENS160+BME280 Breakout

DFRobot

No reviews yet Write a Review
SKU:
147-SEN0335
MPN:
SEN0335
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹2,959.44 inc. GST
₹2,508.00 ex. GST
15 people looking at this.

Technical Specifications

Brand:
DFRobot
Target Gas:
Air Quality
Operating Voltage:
3.3V
Working Current:
<20mA
Dimension:
22x28mm

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

This multi-function environment sensor module can be used to build a simple environmental monitor station. It features the ENS160+BME280 chip combination, providing high accuracy, I2C interface, and fast measurement capabilities. The BME280 temperature and humidity compensation feature improves the overall accuracy of the ENS160 sensor. The module is capable of detecting temperature, humidity, barometric pressure, altitude, TVOC, and eCO2.

The ENS160 air quality sensor is specifically designed for indoor air quality monitoring and can detect multiple IAQ data, including TVOC, eCO2, and AQI. The sensor utilizes ScioSense's new ENS160 sensor chip and features innovative TrueVOC technology, combining metal oxide (MOX) technology for superior accuracy, fast response, and anti-interference.

The BME280 environmental sensor combines a temperature sensor, humidity sensor, and barometer in one board, offering high precision, multiple functions, and a small size. It provides a +-0.5C temperature error and a +-2%RH humidity error, with very stable performance within the detection temperature range. Additionally, the offset temperature coefficient is +-1.5 Pa/K, equivalent to +-12.6 cm at a 1C temperature change.

Specifications
ENS160 Parameter:
  • Preheat Time: <3 minutes
  • I2C Address: 0x53(default), 0X52
  • Operating Temperature Range: -40~85C
  • Operating Humidity Range: 5%RH~95%RH
  • eCO2 Measuring Range: 400ppm~65000ppm
  • TVOC Measuring Range: 0ppb~65000ppb
BME280 Parameter:
  • I2CAddress:0x76(default), 0X77
  • Operating Temperature: -40C~85C
  • Temperature Measuring Range: -40C~+85C, resolution of 0.1C, deviation of +-0.5C
  • Humidity Measuring Range: 0~100%RH, resolution of 0.1%RH, deviation of +-2%RH
  • Pressure Measuring Range: 300~1100hPa
