Air Filter For BD-04 and BD-07 Series Micro Pumps With White Polymer Filter Element For Cleaner Intake Air And Stable Airflow
The BD-AF01 is an air filter made for BD-04 and BD-07 series micro pumps. It captures airborne particles before they enter the pump, which helps protect internal components and keeps airflow stable. The white polymer filter element sits inside a modified PP housing, giving a light and compact inline protection stage for the pump.
The filter measures 60 x dia. 28.5 mm and weighs approx. 5.4 g, so it adds very little bulk to the system. It works with ID 5 mm x OD 8 mm PU tubing and ID 5 mm x OD 10 mm silicone tubing. Service life is typically more than 3 months, depending on the operating environment and contamination level. Regular inspection and timely replacement help prevent blockage and extend pump service life.
Key Features
- Particle Filtration: Filters airborne particles before they reach the pump.
- Pump Protection: Helps protect internal pump components from contamination.
- Stable Airflow: Helps maintain consistent airflow by keeping the intake clean.
- Polymer Filter Element: White polymer filter element for air filtration.
- Durable Housing: Modified PP housing keeps the filter light and compact.
- Compact Size: 60 x dia. 28.5 mm, well-suited for space-limited layouts.
- Lightweight Build: Approx. 5.4 g, adding negligible weight to the setup.
- Tubing Compatibility: Works with ID 5 mm x OD 8 mm PU tube and ID 5 mm x OD 10 mm silicone tube.
- Port Size: Inlet and outlet port of ID 4.0 mm and OD 7.0 mm.
- Service Life: Typically more than 3 months, depending on the operating environment and contamination level.
Applications
- Air pumping and air sampling systems
- Laboratory and analytical instruments
- Medical and healthcare devices using micro pumps
- Portable and battery-powered devices
- Home appliances and small automation systems
- DIY, prototyping and R&D projects
