USB to FCC 10Pin 1.0mm Adapter Board HDL662B LCM LCD Module Debugging Interface

DWIN

No reviews yet Write a Review
SKU:
353-HDL662B
MPN:
HDL662B
Quantity
Unit Price (ex. GST)
1 - 9
₹ 435.00
10 - 99
₹ 413.25
100 or above
₹ 391.50
The USB to FCC 10-pin 1.0mm Adapter Board provides seamless connectivity between USB and FCC 10-pin 1.0mm interfaces. It simplifies integration and offers flexibility for various projects requiring easy USB-to-FCC connection. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹513.30 inc. GST
₹435.00 ex. GST
23 people looking at this.

Technical Specifications

Brand:
DWIN

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

The DWIN HDL662B Adapter Board is used to debug the LCM LCD Modules / LCD displays. The board has a USB connector on one side and 10 pins 1mm pitch FFC connector on the other side. Users can connect it through the USB interface directly to a PC without an additional power supply. A 10PIN FFC cable is needed to connect the PC and USB adapter plate when using DWIN C-series products.

Resources

HDL662B USB to FCC 10Pin 1.0mm Adapter Board Interfacing

DWIN Smart LCD Display Accessories (Need to purchase separately)

FAQs about DWIN Smart LCD Screens

Question 1: How can I start development with a DWIN LCD Module? Can I assemble it directly to my machine?
Answer: No, you should update the program to LCD first, and then assemble it.
Step 1: Check the software platform of the screen, it mentioned in datasheet.
Step 2: Use the correct development SDK (different platform use different SDK) to finish development.
Step 3: Update software program and test
Step 4: When test is OK, assemble it on machine.

Question 2: How to update the program to DWIN LCD?
Answer: 1. Via serial port ( use Download tool in SDK)
             2. Via Micro SD card

Question 3: I want to use PLC with modbus protocol. Is modbus supported?
Answer: Yes of course, after download modbus kernel, DWIN screen will support modbus protocol. (some module not support update modbus kernel, please check with DWIN service before buying)

Question 4: Do DWIN LCD displays support video or audio playback?
Answer: Yes, all the LCD which with speaker interface support playing audio. Multi-media product support analog video and digital video.

Question 5: Why my screen does not produce beep sound when I touch the button?
Answer: 1) Check if the LCD have buzzer in hardware.  (see picture below)












2) Check if the touch tone register set ON.

Question 6: How to format the SD card and update the LCD program?
Answer: Memory of SD card: 2GB/ 4GB/ 8GB/ 16GB
             Format SD card following below step:
Create a “DWIN_SET” folder in the root directory of SD card and copy all the files (such as picuctures, fonts and config files ) into that “DWIN_SET” folder.

Question 7: Which industries and machines can use DWIN smart LCD displays?
Answer : The DWIN smart LCD modules / smart screens / smart displays can be used for Android Touch Panel, HMI Touch Panel, Smart LCD Display Module, Smart Touch LCD Module, Smart Touch Screen Display, Industrial Touch LCD Display, PLC Display Screen, Serial Port LCD Display, STM32 MCU Displays etc.
These displays can be used in many industrial equipments and devices like  Health and fitness equipments, Medical devices, Air treatment devices, Transportation (Car & Ship instruments), instruments and apparatus automation, IC design and manufacture, Kitchen appliances (Juicer, micro-oven , ice machine, ice-cream machine, kitchen ventilator), New energy (Photovoltaic, Wind electricity, Charging Staion), Household appliances and many more.
