Tactile Switch 4 pin Round Button SPST 6.2x6.2x3.1mm - TS6631A4P

SHOU HAN

No reviews yet Write a Review
SKU:
336-TS6631A4P
Manufacturer Part Number:
TS6631A4P
Full Reel Quantity:
1500 (to receive in standard manufacturer packaging, please order in multiples of this quantity)
₹4.13 inc. GST
₹3.50 ex. GST
TS6631A4P 4 pin Round Button Tactile Switch with Lamp SPST 6.2x6.2x3.1mm 12V 50mA
Buy 10 - 99
15% off
Buy 100 or above
30% off
₹4.13 inc. GST
₹3.50 ex. GST

Description

This 4 pin Round Button Tactile Switch SPST is 6.2mm in switch width, 3.1mm in switch height, and 6.2mm in switch length, featuring a round button actuator style. The switch is designed for brick nogging mounting and includes a lamp. With a contact current of 50mA and a voltage rating of 12V DC, this switch is ideal for a variety of applications. The circuit configuration is SPST, and the mechanical life is not specified.

Resources



Technical Specifications

Brand:
SHOU HAN
Mount:
Surface Mount
336-TS6631A4P:
4
Current Rating:
50 mA
Orientation:
Straight
Throw Configuration:
SPST
Voltage Rating:
12 V
Size (LxWxH):
6.2x6.2x3.1 mm
Max Operating Temperature:
70 C
Min Operating Temperature:
-20 C
Operating Force:
250 gf
Action Type:
Momentary
Contact Resistance:
< 100 mOhm
Insulation Resistance:
> 50 mOhm (100V DC)
Switching Life:
100000 Cycles
Full Reel Quantity:
1500

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.
