High Power 12V 15A SPDT (1 Form C) Through Hole Relay for Reliable PCB Switching and Control Applications
The SRD 12V 15A 1 Form C high power relay is designed for efficient and dependable switching of high-current loads in electronic and electrical systems. Operating with a 12V DC coil, this relay is ideal for automotive circuits, industrial automation, and embedded control applications. With a contact rating of up to 15A, it can handle loads such as motors, lighting systems, power supplies, and household appliances. The SPDT (Single Pole Double Throw) configuration supports both normally open (NO) and normally closed (NC) operations, offering flexibility in circuit design and switching control.
With a compact footprint of 19.2 x 15.6mm, this through-hole relay ensures easy PCB integration while maintaining strong mechanical stability. It provides excellent electrical isolation between control and load circuits, enhancing safety and reliability in high-power applications. The SRD series is widely used in automation systems, IoT devices, and power management circuits due to its consistent performance, long operational life, and efficient switching characteristics.
Key Features:
- High Current Capacity: Supports up to 15A load current for reliable switching
- 12V DC Coil Voltage: Suitable for automotive, industrial, and control applications
- SPDT (1 Form C) Configuration: Enables both Normally Open (NO) and Normally Closed (NC) switching
- Compact Size: 19.2mmx15.6mm for efficient PCB layout
- Through Hole Mounting: Ensures secure soldering and stable PCB installation
- Wide Application Range: Ideal for automation, appliances, and embedded systems
- Reliable Performance: Long electrical and mechanical life
- Electrical Isolation: Protects control circuits from high voltage and current loads
