SparkFun Red Vision Touch Display Interface Board For RedBoard (Without Display)

SparkFun

No reviews yet Write a Review
SKU:
057-LCD-30217
MPN:
LCD-30217
SparkFun Red Vision Touch Display interface board without LCD for RedBoard
SparkFun Red Vision Touch Display interface board without LCD for RP2350 RedBoard IoT. Provides camera connectivity, R3 shield footprint, I/O expander, and support for external video output solutions. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹2,016.88 inc. GST
₹1,709.22 ex. GST
19 people looking at this.

Technical Specifications

Brand:
SparkFun
Display:
Not included
Logic Level:
3.3 V
Shield Interface:
R3 Arduino Footprint
Headers:
2x8 pin, 1x10 pin, 1x6 pin male headers
Camera Connector:
2x10 Socket
Onboard Components:
I/O expander, red power LED
Primary Software Support:
RP2350 RedBoard IoT

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:

SparkFun Red Vision Touch Display Interface Board for RedBoard without Onboard LCD

The SparkFun Red Vision Touch Display for RedBoard (Without Display) is a purpose-built interface board for developers who want to leverage the Red Vision camera ecosystem while routing video output to an external display or monitor. By omitting the onboard LCD, this version provides a clean and flexible solution for advanced computer vision projects where a larger screen or custom video output hardware is preferred. Designed to fit the standard R3 shield footprint, the board plugs directly into the RP2350 RedBoard IoT, maintaining a compact and reliable stack without external wiring.

This interface board acts as a high-speed bridge between the Red Vision Camera and the RP2350 RedBoard IoT, while keeping critical pins accessible for alternative video or display solutions. It includes an onboard I/O expander to support additional peripherals and a red power LED for clear system status indication. While the hardware layout is compatible with other 3.3 V logic RedBoards or R3-style Arduino boards with sufficient processing capability, the Red Vision software ecosystem is currently optimised for the RP2350 platform.

Key Features:

  • Vision Interface Board: Designed for Red Vision camera integration without an onboard LCD
  • Display Flexibility: Allows use of larger external displays or custom video output hardware
  • Form Factor: Standard R3 shield footprint for direct RedBoard mounting
  • Board Compatibility: Optimised for RP2350 RedBoard IoT and 3.3 V logic R3 boards
  • Camera Connectivity: 2x10 socket for connecting a compatible Red Vision camera board
  • I/O Expansion: Integrated I/O expander for additional peripheral control
  • Connectivity: Male R3 headers including 2x8-pin, 1x10-pin, and 1x6-pin headers
  • Status Indicator: Onboard red power LED for quick visual feedback.
