Silicone Vibration-Damping Bracket For BD-07 Series Micro Pumps With 42 mm Inner Diameter For Quiet, Vibration-Free Pump Mounting
The BD-S507 is a silicone vibration-damping bracket made for BD-07 series micro pumps. Its flexible silicone body cushions the pump and absorbs the vibration produced while it runs. This reduces operating noise and limits the mechanical impact that reaches the enclosure or frame.
The bracket has a 42 mm inner diameter and measures approx. 64 x 12 x 53 mm, so it fits neatly into compact equipment layouts. Each bracket weighs approx. 10 g, and 2 brackets are used per pump. The eco-friendly silicone also helps cut down wear on the pump body, which makes it a dependable choice for systems that run for long hours.
Key Features
- Vibration Damping: Flexible silicone absorbs pump vibration before it reaches the mounting surface.
- Noise Reduction: Helps lower operating noise from BD-07 series micro pumps.
- Secure Installation: The flexible structure holds the pump firmly in place.
- Reduced Wear: Helps minimise mechanical impact and wear on the pump and surrounding parts.
- Defined Fit: 42 mm inner diameter, designed for BD-07 series micro pumps.
- Two-Bracket Mounting: 2 pcs of brackets are used per pump.
- Compact Size: Approx. 64 x 12 x 53 mm, well-suited for space-limited designs.
- Lightweight Build: Approx. 10 g per bracket, adding very little weight to the system.
- Eco-Friendly Material: Made from eco-friendly silicone.
Applications
- Medical and healthcare devices using micro pumps
- Laboratory and analytical instruments
- Air and liquid sampling equipment
- Portable and battery-powered devices
- Home appliances and small automation systems
- DIY, prototyping and R&D projects
- Low-noise enclosures and compact machines
