M5Stack M5Stack ESP32 FIRE IoT Development Kit V2.7

M5Stack

No reviews yet Write a Review
SKU:
558-K007-V27
MPN:
K007-V27
M5Stack K007-V27 FIRE v2.7 ESP32 IoT development kit with IPS display, MPU6886 IMU, RGB LEDs, and M5GO base
M5Stack K007-V27 FIRE v2.7 is an ESP32 IoT development kit featuring 16MB Flash, 8MB PSRAM, a 2.0-inch IPS display, MPU6886 6-axis IMU, 10 RGB LEDs, microphone, speaker, 500mAh battery, TF card slot, and three Grove expansion ports. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹8,417.06 inc. GST
₹7,133.10 ex. GST
19 people looking at this.

Technical Specifications

Brand:
M5Stack
SoC:
ESP32-D0WDQ6@Dual-core processor, Main frequency 240MHz
DMIPS:
600
SRAM:
520KB
Flash:
16MB
PSRAM:
8MB
Wi-Fi:
2.4 GHz Wi-Fi
Power Input:
5V@500mA
Interface:
USB Type-C x1, POGO PIN x1, I2C x1, GPIO x1, UART x1
Buttons:
Physical buttons x 3
LCD Screen:
2.0 inch @320 x 240 ILI9342C IPS panel, max brightness 853nit
Speaker:
1W-0928
Microphone:
Analog BSE3729 Microphone
IMU:
6-axis MPU6886
USB Chip:
CH9102F
LED:
SK6812 RGB LED x 10
Antenna:
2.4G 3D antenna
Battery:
500 mAh @ 3.7V
Casing Material:
Plastic (PC)
Product Size:
54.0x54.0x28.6mm
Product Weight:
88.8g
Package Size:
106.7x69.1x40.4mm
Gross Weight:
148.6g

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:
Documents

ESP32 IoT Development Kit with 8MB PSRAM, 2.0-Inch IPS Display, and MPU6886 IMU

The M5Stack K007-V27 FIRE IoT Development Kit v2.7 is a feature-rich ESP32-based controller designed for IoT development, product prototyping, smart building systems, industrial control, and maker applications. It uses the ESP32-D0WDQ6-V3 with a dual-core Xtensa 32-bit LX6 processor running at up to 240 MHz and combines 16MB Flash with 8MB Quad PSRAM for applications that require additional program and working memory.

The controller integrates a 2.0-inch 320 × 240 IPS display, MPU6886 6-axis IMU, microphone, 1W speaker, 10 programmable RGB LEDs, three physical buttons, TF card slot, and a 500mAh lithium battery. Three HY2.0-4P Grove interfaces provide I2C, GPIO, and UART connectivity, while the M5-Bus supports stackable M5Stack modules and additional interfaces including ADC, DAC, SPI, and serial communication. The included M5GO bottom and charging base support convenient portable development and structural integration with compatible 8 mm LEGO-style components.

Key Features

  • ESP32-D0WDQ6-V3 dual-core processor operating at up to 240 MHz
  • 16MB Flash memory
  • 8MB Quad PSRAM
  • 520KB SRAM
  • 2.4 GHz Wi-Fi connectivity
  • 2.0-inch 320 × 240 IPS color display
  • ILI9342C display controller
  • Glass display panel
  • Maximum display brightness up to 853 nits
  • MPU6886 6-axis IMU
  • 10 × programmable SK6812 RGB LEDs
  • Built-in analog microphone
  • Built-in 1W speaker
  • 3 physical programmable buttons
  • 500mAh 3.7V lithium battery
  • IP5306 power-management IC
  • Onboard TF / microSD card slot
  • CH9102F USB-to-serial interface
  • USB Type-C power and programming interface
  • POGO-pin power interface
  • 3 × HY2.0-4P Grove expansion ports
  • Port A for I2C
  • Port B for GPIO
  • Port C for UART
  • M5-Bus expansion for stackable modules
  • Supports ADC, DAC, I2C, UART, and SPI resources
  • M5GO bottom compatible with 8 mm LEGO-style building elements
  • Microsoft Azure Certified Device
  • Supports FreeRTOS multitasking
  • Supports UiFlow1, UiFlow2, Arduino IDE, ESP-IDF, and PlatformIO

Applications

  • IoT controller development
  • Smart home control
  • Smart building systems
  • Industrial control prototypes
  • Environmental monitoring systems
  • Wireless data-collection nodes
  • Human-machine interfaces
  • Motion-sensing applications
  • Portable embedded systems
  • RGB lighting projects
  • Maker and DIY projects
  • Educational programming
  • Product prototype development
  • Sensor and actuator control

Package Includes:

  • 1 x M5Stack FIRE
  • 1 x M5GO charging base
  • 2 x LEGO bricks
  • 5 x LEGO connectors
  • 1 x M3 hex wrench
  • 1 x USB Type-C cable (50cm)
  • 1 x User manual
