Name: Gravity: Offline Edge AI Gesture & Face Detection Sensor
Brand: DFRobot
SKU: 147-SEN0626
Price: 1662.93 INR
Availability: InStock

Technical Specifications

Brand:

DFRobot

Operating Voltage:

3.3V – 5V

Logic Level Voltage:

3.3V

Current Consumption:

100mA

Connector Type:

PH2.0-4P / 2.54mm pin header

Communication Protocols:

I2C / UART

I2C Address:

0x72

Default UART Baud Rate:

9600bps

UART Protocol:

Modbus

Interrupt Output:

2.54mm pin header

Supported Gesture Types (5):

Thumbs up Extend the middle, ring, and little fingers, Open palm facing outward,Extend the index and middle fingers,Extend the thumb and little finger

Maximum Recognizable Faces & Head-Shoulder Count:

Detection Area for Face & Shoulders:

Recognizes upper-body presence within camera range

Face Recognition Confidence Score:

0 – 100

Position Coordinate Output:

Supported

Gesture Recognition Distance:

0.5m – 3m

Face Recognition Distance:

0.5m – 3m

Camera Field of View (FoV):

85° (diagonal)

Camera Focal Length:

1.56mm

PCB Dimensions:

42mm × 32mm

Mounting Hole Spacing:

25mm × 35mm

Mounting Hole Diameter:

3.1mm

Blue:

Thumbs up

Green:

Extend the middle, ring, and little fingers

Red:

Open palm outward

Yellow:

Extend the index and middle fingers

Purple:

Extend the thumb and little finger

Presence Detection LED:

Illuminates when a person is detected, turns off when no presence is detected

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Offline Edge AI Sensor for Gesture & Face Detection Applications: – 5 Gestures, 10 Faces, 3m (Arduino/ RPi/ ESP32)

The Gravity: Offline Edge AI Gesture & Face Detection Sensor is made for multi-person presence detection and easy gesture control. With its built-in camera and AI processor, the sensor can concurrently identify up to 10 faces or upper-body presences within a 3-meter range and recognize five predetermined hand signals. It provides responsive and private interaction without relying on the cloud by fusing real-time edge AI computing with computer vision.

This module is completely compatible with Arduino, Raspberry Pi, ESP32, and graphical systems like MakeCode and Mind+. It has two communication interfaces (I2C and UART) and supports a wide voltage range (3.3V–5V). It is perfect for public engagement devices, touchless control systems, smart home interfaces, and privacy-focused Internet of Things applications.

Edge AI Processing: Offline, Real-Time, and Private

The inbuilt AI engine handles all recognition operations locally; no data is sent to the cloud or stored there. For sensitive applications like hospital automation, bathroom controls, children's systems, or public facilities, this fully offline operation ensures data privacy. It is appropriate for power-sensitive or standalone applications since, despite its strong capabilities, it typically uses only 100mA.

Recognizes 5 Intuitive Hand Gestures – Touchless Control Made Easy

The sensor can identify up to ten human faces or presences at once, detect head-and-shoulder patterns, and provide real-time position and count output in addition to gesture control. With complete offline privacy assurance, it's ideal for occupancy-based HVAC, lighting automation, and people counts in offices, stores, and smart spaces.
