Gravity: Digital 10A Relay Module

DFRobot

No reviews yet Write a Review
SKU:
147-DFR0473
Manufacturer Part Number:
DFR0473
₹396.48 inc. GST
₹336.00 ex. GST
₹396.48 inc. GST
₹336.00 ex. GST
18 people looking at this.

Description

The Gravity Digital Relay Module is a device that allows you to control and switch electrical loads using a low-voltage control signal. It is compatible with a wide range of devices, including 5V Arduino boards, Raspberry Pi, BBB (BeagleBoard Black), mbed, Intel Joule, and Arduino 101, among others. This makes it a versatile and flexible choice for a variety of projects and applications.

One of the key features of this relay module is its ability to work well under 3.3V power supplies, which makes it suitable for use with low-voltage devices like the Raspberry Pi. It also has a wide range of power input capabilities, and in tests, it has been shown to be able to support 1.8V devices once it reaches a voltage range of 2.8-5.5V.

The Digital Relay Module uses a high-quality 3V relay that is capable of handling up to 10A of current. Its mechanical parts are also guaranteed for up to 100 million uses, which makes it a reliable and durable choice. The module also includes an on-board indicator LED to demonstrate the relay's state, and it has terminals for normally open (NO) and normally closed (NC) connections.

Overall, the Gravity Digital Relay Module is a convenient and easy-to-use device that can be used to control and switch electrical loads in a variety of projects and applications. Its Gravity-3 pin interface allows for easy plug-and-play usage without the need for soldering.

Features
  • Supports Arduino, Raspberry Pi, LattePanda etc.
  • 2.8 ~ 5.5V – A wide-range of input voltages
  • The underside of board is isolated using an acrylic plate for safety
  • Includes an LED Indicator
  • Uses a gravity-3 Pin interface for easy, plug and play usage
Package Contents
  • Gravity: Digital Relay Module (with Acrylic Base) x 1
  • Gravity Digital Sensor Cable x 1
Resources


Technical Specifications

Brand:
DFRobot
Operating Voltage:
2.8V ~ 5.5V
Input Signal:
High Level (>=2.8V); Low Level (
Max Switching Current:
10A
Max Switching Voltage:
35VAC; 30VDC
Rating Load:
10A@35VAC; 10A@28VDC
Max Switching Power:
300W
Operate Time:
< = 10ms
Release Time:
< = 5ms
Dimensions:
38 x 33 x 20 mm
Mechanical Life:
1 million uses
Electrical Life:
50 thousand uses
Weight:
20g
