G2R-1-E/12VDC - 12V 16A 1FormC High Power Relay Through Hole 28.6x12.6mm

Omron Electronics

No reviews yet Write a Review
SKU:
169-G2R-1-E-12VDC
MPN:
G2R-1-E/12VDC
G2R 12V 16A SPDT 1 Form C high power relay through hole 28.6x12.6mm PCB relay for industrial control systems
Quantity
Unit Price (ex. GST)
1 - 9
₹ 204.24
10 - 99
₹ 194.03
100 or above
₹ 183.82
12V 16A SPDT (1 Form C) high power relay with through-hole mounting. Ideal for industrial automation, appliances, and high-current PCB switching. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹241.00 inc. GST
₹204.24 ex. GST

Technical Specifications

Brand:
Omron Electronics
Package:
Through Hole
Size:
28.8x12.7mm
Contact Material:
Silver Alloy (Cd-Free)
Coil Voltage:
12V
Number of Pins:
8
Operating Temperature:
-40 C~+70 C
Release Time:
5ms
Operate Time:
15ms
Switching Current(Max):
16A
Contact Form:
One set changeover: 1C (SPDT - changeover)
Contact Resistance:
30mOhm
Coil Rated Power:
530mW
Coil Resistance:
275Ohm
Coil Type:
Non-Polarized - Single Coil

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:
Datasheet

High Power 12V 16A SPDT (1 Form C) Through Hole Relay for Industrial Load Switching and Control Systems

The G2R 12V 16A 1 Form C high power relay is a robust electromechanical switching device engineered for demanding industrial and embedded applications. Operating with a 12V DC coil, this relay supports high current switching up to 16A, making it suitable for controlling heavy loads such as heaters, motors, compressors, and power supply circuits. The SPDT (1 Form C) configuration allows flexible switching between normally open (NO) and normally closed (NC) contacts, enabling versatile control in automation systems.

Built with a durable through-hole PCB mount design (~28.6x12.6mm footprint), the G2R series ensures reliable performance, strong insulation, and long operational life. It features fast switching (~15ms operate, ~5ms release), low contact resistance, and high mechanical durability (~20 million operations), making it ideal for continuous-duty applications in industrial control panels, appliances, and energy systems.

Key Features

  • 16A High Switching Capacity: Suitable for heavy-duty industrial loads
  • 12V DC Coil Voltage: Ideal for automation and embedded systems
  • SPDT (1 Form C): Supports both NO and NC switching
  • Through Hole Mounting: Secure PCB installation
  • Compact Power Design: ~28.6mmx12.6mm footprint
  • Fast Switching Performance: ~15ms operate, ~5ms release
  • High Mechanical Life: Up to ~20 million operations
  • Durable Contacts: Silver alloy contacts for long service life
  • Wide Operating Temperature: -40°C to+70°C
