G2R-1 DC12 - 12V 10A 1FormC High Power Relay Through Hole 28.8x12.7mm

Omron Electronics

No reviews yet Write a Review
SKU:
169-G2R-1-DC12
MPN:
G2R-1 DC12
G2R 12V 10A SPDT 1 Form C high power relay through hole 28.8x12.7mm PCB relay for industrial control systems
Quantity
Unit Price (ex. GST)
1 - 9
₹ 252.16
10 - 99
₹ 239.55
100 or above
₹ 226.94
12V 10A SPDT (1 Form C) high power relay with through-hole mounting. Ideal for industrial automation, appliances, and PCB switching applications. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹297.55 inc. GST
₹252.16 ex. GST
14 people looking at this.

Technical Specifications

Brand:
Omron Electronics
Package:
Through Hole
Size:
28.8x12.7mm
Contact Material:
Silver Alloy (Cd-Free)
Coil Voltage:
12V
Number of Pins:
5
Operating Temperature:
-40 C~+70 C
Release Time:
5ms
Operate Time:
15ms
Switching Current(Max):
16A
Contact Form:
One set changeover: 1C (SPDT - changeover)
Contact Resistance:
30mOhm
Coil Rated Power:
530mW
Coil Resistance:
275Ohm
Coil Type:
Non-Polarized - Single Coil

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:
Datasheet

High Power 12V 10A SPDT (1 Form C) Through Hole Relay for Industrial Switching and Control Applications

The G2R 12V 10A 1 Form C high power relay is a reliable electromechanical relay designed for medium-to-high load switching in industrial and embedded systems. Operating with a 12V DC coil, this relay supports up to 10A switching capacity and features an SPDT (1 Form C) configuration, enabling flexible switching between normally open (NO) and normally closed (NC) contacts. It is widely used in automation systems, control panels, home appliances, and power management circuits where stable and dependable switching is required.

Built with a standard through-hole PCB mount design (~28.8x12.7mm), the G2R series ensures strong mechanical stability and easy integration into circuit boards. The relay offers fast switching (~15ms operate, ~5ms release), high insulation strength (up to ~5kV coil-to-contact), and durable silver alloy contacts for long operational life. Its compact yet rugged construction makes it suitable for continuous-duty industrial environments.

Key Features

  • 10A Switching Capacity: Suitable for medium power load control
  • 12V DC Coil Voltage: Ideal for automation and embedded systems
  • SPDT (1 Form C): Supports NO and NC switching configurations
  • Through Hole Mounting: Secure PCB installation
  • Compact Design: ~28.8mmx12.7mm footprint
  • Fast Switching Performance: ~15ms operate, ~5ms release
  • High Insulation Strength: Up to ~5kV coil-to-contact isolation
  • Durable Contacts: Silver alloy contacts for long service life
  • Wide Operating Temperature: -40 C to+70 C
