7Semi Human Presence and Motion Sensor FOV 80deg STHS34PF80 - 4 Meters

7Semi

No reviews yet Write a Review
SKU:
004-ES-12267
MPN:
ES-12267
7Semi STHS34PF80 human presence and motion sensor board with 6 pin 2.5 mm connector
7Semi STHS34PF80 based human presence and motion sensor with 80 degree field of view, 4 meter detection range, low power operation, and 6 pin 2.5 mm connector for simple microcontroller integration. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹1,001.82 inc. GST
₹849.00 ex. GST
16 people looking at this.

Technical Specifications

Brand:
7Semi
Supply Voltage:
3.3 V
Supply Current:
10 uA
Interface:
I2C or 3 wire SPI
Programmable Output Data Rate:
0.25 Hz to 30 Hz
One Shot Mode:
Supported
IR Sensitivity:
2000 LSB per C
Operating Wavelength:
5 um to 20 um
Sensing Range:
Up to 4 meters
Field of View:
80 degrees
Connectivity:
6-Pin JST XH 2.5mm Side Entry
Board Pins:
3V3, GND, SCL, SDA, CS, INT
Indicators:
Red Power LED
Mounting:
Four mounting holes
I2C Address:
0x5A (Default)

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources

7Semi Human Presence and Motion Sensor FOV 80deg STHS34PF80 4 Meters with 6Pin 2.5mm Connector

The 7Semi Human Presence and Motion Sensor is designed around the STHS34PF80 infrared sensing device for reliable presence and motion detection within an 80 degree field of view. It supports up to 4 meter sensing distance, making it suitable for smart lighting, security, and occupancy monitoring systems.

This compact board uses a 6 pin 2.5 mm SMD JST XH side entry header for simple integration with microcontrollers. It provides stable operation under varied lighting conditions due to its 5 to 20 micrometer optical band pass filter, factory calibration, and built in algorithms capable of identifying both stationary and moving objects.

Features

• High sensitivity detection Human presence and motion detection up to 4 meters
• Wide field of view 80 degree coverage
• Stable performance Integrated silicon IR filter for consistent readings
• Smart algorithms Able to differentiate stationary and moving targets
• Low power design Suitable for battery powered IoT devices
• Easy integration 6 pin header with 3V3 GND SCL SDA CS INT
• Factory calibrated Ensures accurate thermal and infrared measurements

Applications
• Presence and proximity sensing
• Alarm / security systems
• Home automation
• Smart lighting
• IoT
• Smart lockers
• Smart wall pads
