Tactile Switch 4-Pin SPST Momentary SMD 3.3x3.3x2.0 mm - TS3320A

SHOU HAN

No reviews yet Write a Review
SKU:
336-TS3320A
Manufacturer Part Number:
TS3320A
Full Reel Quantity:
4000 (to receive in standard manufacturer packaging, please order in multiples of this quantity)
Sale
Was:
₹5.78
₹4.90
₹4.05 inc. GST
₹3.43 ex. GST
TS3320A - Tactile Switch 4-Pin SPST Momentary SMD, Brick Nogging Mount
Buy 10 - 99
15% off
Buy 100 or above
30% off
Was:
₹5.78
₹4.90
₹4.05 inc. GST
₹3.43 ex. GST
19 people looking at this.

Description

SPST Round Button Tactile Switch SMD is a 12V 50mA switch with a black round button actuator. The switch has a brick nogging mount and a length of 3.3mm. It has an insulation resistance of 100MOhm and a mechanical life of 50,000 cycles. This tactile switch allows electricity to flow in an electrical circuit by manually pressing the operating section. The switch is used to supply an input signal to actuate a device or equipment. These switches are commonly used in many consumer and industrial electronic devices.

Resources



Technical Specifications

Brand:
SHOU HAN
Mount:
Surface Mount
Number of Pins:
4
Current Rating:
50 mA
Orientation:
Straight
Throw Configuration:
SPST
Voltage Rating:
12 V
Size (LxWxH):
3.3x3.3x2.0 mm
Max Operating Temperature:
70 C
Min Operating Temperature:
-20 C
Operating Force:
250 gf
Action Type:
Momentary
Contact Resistance:
< 100 mOhm
Insulation Resistance:
> 100MOhm (100V DC)
Switching Life:
50000 Cycles
Full Reel Quantity:
4000
