Tactile Switch 4-Pin SPST 160gf SMD Rectangular Button - TSC4A 160gf-WZ 016

SHOUHAN

No reviews yet Write a Review
SKU:
336-TSC4A-160gf-WZ-016
MPN:
TSC4A 160gf-WZ 016
TSC4A 160gf-WZ 016 4-pin SPST SMD rectangular tactile push-button switch with 160 gf operating force
Quantity
Unit Price (ex. GST)
1 - 9
₹ 12.00
10 - 99
₹ 10.80
100 - 999
₹ 9.60
1000 or above
₹ 8.40
TSC4A 160gf-WZ 016 is a 4-pin SPST normally-open SMD tactile switch with 160 gf operating force and rectangular push-button design for compact PCB control applications. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹14.16 inc. GST
₹12.00 ex. GST
21 people looking at this.

Technical Specifications

Brand:
SHOUHAN
Package/Case:
SMD
Length:
3.5mm
Height:
1.5mm
Operating Force:
1.6N
Voltage Rating:
12V
Switching Life:
100,000 Cycles
Width:
3mm
Operating Temperature:
-20 C~+70 C
Actuator Style:
Rectangular Button
Termination Style:
SMD(SMT) Tab
With Lamp:
No
Mounting Type:
Surface Mount, Right Angle
Circuit:
SPST
Actuator/Cap Color:
Black
Contact Current:
50mA

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:
Datasheet

4-Pin SPST SMD Tactile Switch With 160 gf Operating Force For PCB Control Applications

The TSC4A 160gf-WZ 016 is a compact 4-pin SPST tactile switch designed for surface-mount PCB applications requiring a momentary push-button input. Its 160 gf operating force provides a defined tactile response for user-interface controls, reset functions, menu buttons, mode selection, and compact electronic devices. The rectangular SMD format supports efficient placement on densely populated circuit boards.

Designed for low-profile control interfaces, the switch uses a normally-open SPST contact arrangement that closes momentarily when the actuator is pressed. Its 4-pin construction helps provide stable PCB mounting while maintaining a simple switching function. The device is suitable for consumer electronics, embedded controllers, IoT devices, development boards, handheld products, and other compact electronic assemblies requiring reliable manual input.

Key Features

  • SPST Configuration: Normally-open single-pole single-throw momentary switching action
  • 160 gf Operating Force: Provides a defined tactile response during button actuation
  • 4-Pin Design: Offers secure PCB mounting and straightforward circuit integration
  • SMD Construction: Designed for surface-mount PCB assembly
  • Rectangular Form Factor: Suitable for compact control-panel and embedded-device layouts
  • Momentary Operation: Contact remains closed only while the button is pressed
  • Compact PCB Integration: Well-suited for space-constrained electronic products
  • User-Input Function: Suitable for reset, menu, navigation, mode, and control-button applications

Applications

  • Embedded-system control buttons
  • Development boards
  • IoT devices
  • Consumer electronics
  • Reset switches
  • Menu and navigation controls
  • Handheld electronic devices
  • Smart-home products
  • Industrial control panels
  • Remote-control devices
  • Portable electronics
  • Custom PCB projects
