Tactile Switch 3-Pin SPST with Round Button Actuator, 4.5x4.5x5.5mm - TS4555B3J

SHOU HAN

No reviews yet Write a Review
SKU:
336-TS4555B3J
Manufacturer Part Number:
TS4555B3J
Full Reel Quantity:
1000 (to receive in standard manufacturer packaging, please order in multiples of this quantity)
₹4.13 inc. GST
₹3.50 ex. GST
TS4543B3J 3-Pin SPST Round button Tactile Switch 4.5x4.5x5.5mm 12V, 50mA, Black
Buy 10 - 99
15% off
Buy 100 or above
30% off
₹4.13 inc. GST
₹3.50 ex. GST
7 people looking at this.

Description

This 3 Pin PCPin SPST Round Button Tactile Switch with Black Actuator 12V 50mA features a switch width of 4.5mm, a switch height of 5.5mm, and a switch length of 4.5mm, with a round button actuator style. The switch is designed for lying mounting and has a circuit configuration of SPST. It has a contact current of 50mA and a voltage rating of 12V DC. The switch is suitable for a wide range of applications with an insulation resistance of 100MOhm and a mechanical life of 100000 times. The switch has an operating temperature range of -25C~+70C.

Resources



Technical Specifications

Brand:
SHOU HAN
Mount:
Through Hole
Number of Pins:
3
Current Rating:
50 mA
Orientation:
Straight
Throw Configuration:
SPST
Voltage Rating:
12 V
Size (LxWxH):
4.5x4.5x5.5 mm
Max Operating Temperature:
70 C
Min Operating Temperature:
-20 C
Operating Force:
250 gf
Action Type:
Momentary
Contact Resistance:
< 100 mOhm
Insulation Resistance:
> 50 mOhm (100V DC)
Switching Life:
100000 Cycles
Full Reel Quantity:
1000
