SMF30CA TVS Diode: Robust ESD & Transient Voltage Protection

Protect your sensitive electronics with the SMF30CA TVS diode. This bidirectional solution offers a 30V working voltage and a 33.3V breakdown voltage for reliable ESD suppression and transient voltage protection. With its 48.4V clamping voltage and 200W peak pulse power dissipation, it safeguards your devices from damaging surges.

Key Features:

Bidirectional protection: Safeguards against surges from either direction.
Compact SOD-123FL package: Ideal for space-constrained designs.
Wide operating temperature range (-55°C to +150°C): Ensures performance in diverse environments.
High ESD rating (30kV contact): Robust defense against electrostatic discharge events.

Technical Specifications:

Polarity: Bidirectional
Channels: 1
Termination Style: SMD/SMT
Package/Case: SOD-123FL
Breakdown Voltage: 33.3 V
Clamping Voltage: 48.4 V
Peak Pulse Power Dissipation: 200 W
ESD Voltage (Contact): 30 kV
ESD Voltage (Air Gap): 30 kV
Peak Pulse Current: 4.1 A
Operating Temperature Range: -55°C to +150°C
Series: SMF
Operating Supply Voltage: 30 V
Power Dissipation: 1 W

Resource

Datasheet

Technical Specifications

Brand:

Case/Package:

SOD-123FL

Mount:

Surface Mount

Number of Pins:

Max Operating Temperature:

150C

Number of Channels:

Min Operating Temperature:

-55C

Clamping Voltage:

48.4 V

Max Breakdown Voltage:

36.8 V

Min Breakdown Voltage:

33.3 V

Peak Pulse Current:

4.1 A

Peak Pulse Power:

200 W

Reverse Voltage:

30 V

Test Current:

1 mA
