Technical Specifications
Brand:
Littelfuse, Inc
Case/Package:
SMA
Mount:
Surface Mount
Number Of Pins:
2
Number of Terminals:
2
Breakdown Voltage:
14 V
Capacitance:
800 pF
Clamping Voltage:
19.9 V
Composition:
Zener
Direction:
Bidirectional
Element Configuration:
Single
Forward Voltage:
3.5 V
Leakage Current:
1 uA
Max Breakdown Voltage:
14.7 V
Max Junction Temperature (Tj):
150 C
Max Operating Temperature:
150 C
Max Output Current:
20.1 A
Max Power Dissipation:
3.3 W
Max Reverse Leakage Current:
1 uA
Max Surge Current:
20.1 A
Min Breakdown Voltage:
13.3 V
Min Operating Temperature:
-65 C
Number of Bidirectional Channels:
1
Number of Channels:
1
Number of Elements:
1
Operating Supply Voltage:
12 V
Peak Pulse Current:
20.1 A
Peak Pulse Power:
400 W
Peak Reverse Current:
1 uA
Polarity:
Bidirectional
Power Line Protection:
No
Power Rating:
400 W
Reverse Breakdown Voltage:
13.3 V
Reverse Standoff Voltage:
12 V
Reverse Voltage:
12 V
Termination:
SMD/SMT
Test Current:
1 mA
Voltage Rating (DC):
12 V
Height:
2.29 mm
Length:
4.5 mm
Width:
2.79 mm
