High Power 12V 30A SPST (1 Form A) Through Hole Relay for Heavy Load Switching and Industrial Applications
The SLA 12V 30A 1 Form A high power relay is designed for robust switching of high-current loads in demanding electrical and electronic systems. Operating on a 12V DC coil, this relay is suitable for automotive circuits, industrial control panels, battery-powered systems, and power distribution units. With a high contact rating of 30A, it can efficiently control heavy loads such as compressors, inverters, heating elements, and high-power lighting. The SPST (Single Pole Single Throw) normally open configuration ensures simple and reliable ON/OFF switching for dedicated load control.
Featuring a larger footprint of 27.6 x 32mm, this through-hole relay provides strong mechanical stability and secure PCB mounting. It offers excellent electrical isolation between control and load circuits, enhancing safety in high-power applications. Built for long operational life and consistent performance, the SLA series relay is widely used in automation systems, UPS units, solar power systems, and industrial electronics where durability and high current handling are critical.
Key Features:
- High Current Capacity: Supports up to 30A load current for heavy-duty switching
- 12V DC Coil Voltage: Compatible with standard control circuits and battery systems
- SPST (1 Form A) Contact: Normally Open (NO) configuration for simple ON/OFF control
- Large Form Factor: 27.6mmx32mm for high-power handling and thermal stability
- Through Hole Mounting: Ensures strong PCB soldering and mechanical reliability
- Heavy Load Applications: Ideal for compressors, heaters, inverters, and power systems
- Reliable Performance: Designed for long electrical and mechanical life
- High Isolation: Provides safe separation between control and high-voltage load circuits
