Technical Specifications
Brand:
onsemi
Case/Package:
SOD-123-2
Material:
Plastic
Number Of Pins:
2
Number of Terminals:
2
Breakdown Voltage:
5.36 V
Element Configuration:
Single
Forward Current:
10 mA
Forward Voltage:
900 mV
Impedance:
60 Ohm
Max Junction Temperature (Tj):
150 C
Max Operating Temperature:
150 C
Max Power Dissipation:
500 mW
Max Reverse Leakage Current:
2 µA
Min Operating Temperature:
-55 C
Number of Elements:
1
Peak Reverse Current:
2 uA
Polarity:
Unidirectional
Power Dissipation:
500 mW
Power Rating:
500 mW
Reference Voltage:
5.1 V
Reverse Standoff Voltage:
2 V
Reverse Voltage:
2 V
Test Current:
5 mA
Tolerance:
5 %
Voltage Rating (DC):
5.1 V
Working Voltage:
5.1 V
Zener Current:
5 mA
Zener Voltage:
5.1 V
Height:
1.35 mm
Length:
2.69 mm
Width:
1.6 mm
Warranty Information
All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.
