Technical Specifications
Brand:
onsemi
Case/Package:
SOD-123-2
Contact Plating:
Tin
Material:
Plastic
Number Of Pins:
2
Number of Terminals:
2
Breakdown Voltage:
9.56 V
Element Configuration:
Single
ESD Protection:
Yes
Forward Voltage:
900 mV
Impedance:
10 Ohm
Max Operating Temperature:
150 C
Max Power Dissipation:
500 mW
Max Reverse Leakage Current:
3 uA
Min Operating Temperature:
-55 C
Number of Elements:
1
Peak Reverse Current:
3 uA
Polarity:
Unidirectional
Power Dissipation:
500 mW
Power Rating:
500 mW
Reference Voltage:
9.1 V
Test Current:
20 mA
Tolerance:
5 %
Voltage Rating (DC):
9.1 V
Zener Current:
20 mA
Height:
1.12 mm
Length:
2.69 mm
Width:
1.6 mm
