Technical Specifications
Brand:
Diodes Incorporated
Case/Package:
SOT-323
Mount:
Surface Mount
Number Of Pins:
3
Number of Terminals:
3
Weight:
6.010099 mg
Collector Base Voltage (VCBO):
40 V
Collector Emitter Breakdown Voltage:
40 V
Collector Emitter Saturation Voltage:
1.2 V
Collector Emitter Voltage (VCEO):
40 V
Continuous Collector Current:
500 mA
Current Rating:
500 mA
Element Configuration:
Single
Emitter Base Voltage (VEBO):
12 V
hFE Min:
14000
Max Breakdown Voltage:
40 V
Max Collector Current:
500 mA
Max Operating Temperature:
150 C
Max Power Dissipation:
200 mW
Min Operating Temperature:
-55 C
Number of Elements:
1
Packaging:
Cut Tape
Polarity:
NPN
Voltage Rating (DC):
40 V
Height:
1 mm
Length:
2.2 mm
Width:
1.35 mm
