Technical Specifications
Brand:
onsemi
Case/Package:
DPAK
Contact Plating:
Tin
Number of Pins:
3
Number of Terminals:
2
Collector Base Voltage (VCBO):
100 V
Collector Emitter Breakdown Voltage:
100 V
Collector Emitter Saturation Voltage:
2 V
Collector Emitter Voltage (VCEO):
100 V
Continuous Collector Current:
8 A
Current Rating:
8 A
Element Configuration:
Single
Emitter Base Voltage (VEBO):
5 V
hFE Min:
100
Max Breakdown Voltage:
100 V
Max Collector Current:
8 A
Max Operating Temperature:
150 C
Max Power Dissipation:
20 W
Min Operating Temperature:
-65 C
Number of Elements:
1
Packaging:
Tape and Reel
Polarity:
NPN
Power Dissipation:
20 W
Transition Frequency:
4 MHz
Voltage Rating (DC):
100 V
Height:
2.38 mm
Length:
6.73 mm
Width:
6.22 mm
