M5Stack M5Stamp C3 Mate with Pin Headers ESP32-C3 Wi-Fi Minimal Core Board

M5Stack

No reviews yet Write a Review
SKU:
558-K056
MPN:
K056
M5Stack K056 M5Stamp C3 Mate minimal core board with ESP32-C3 chip and header pins
M5Stack K056 M5Stamp C3 Mate development board with ESP32-C3 RISC-V 32-bit processor, 160 MHz clock speed, 400 KB SRAM, 4 MB Flash, 2.4 GHz Wi-Fi, USB Type-C interface, 13 GPIO pins, 5V-to-3.3V DC-DC circuit, and pre-soldered header accessories. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹1,011.33 inc. GST
₹857.06 ex. GST
6 people looking at this.

Technical Specifications

Brand:
M5Stack
SoC:
ESP32-C3@32-bit RISC-V Single-Core Processor, Main Frequency up to 160MHz
Flash:
4MB
SRAM:
400KB
ROM:
384KB
RTC SRAM:
8KB
Wi-Fi:
2.4 GHz Wi-Fi (supports 20/40MHz bandwidth, 802.11 b/g/n, up to 150Mbps)
Input Voltage:
5V@500mA
Human-Machine Interaction:
Programmable Physical Button x 1, Reset/Debug Button x 1, Programmable RGB LED (SK6812) x 1
USB Interface:
USB Type-Cx1
Antenna Type:
2.4G 3D Antenna
Module Peripheral Interface Resources:
ADC, GPIO, SPI, UART, I2C, I2S, PWM, RMT, DMA, USB Serial, TWAI
IO Interfaces x13:
G21, G20, G9, G18, G19, G1, G0, G10, G8, G7, G6, G5, G4
IO Interface Pitch:
2.54mm
Mounting Screw Specification:
M2 x 4 Countersunk Hex Socket Machine Screw
Product Size:
34.0x20.0x4.6mm
Product Weight:
4.1g
Package Size:
138.0x93.0x10.0mm
Gross Weight:
9.4g

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:
Documents

M5Stack K056 M5Stamp C3 Mate Board with ESP32-C3 Processor and Pre-Soldered Pin Headers

The M5Stack K056 M5Stamp C3 Mate minimal core board offers a highly integrated, cost-effective development solution powered by the Espressif ESP32-C3 main control chip. Featuring a single-core 32-bit RISC-V microcontroller running at clock speeds up to 160 MHz, this board comes equipped with 400 KB SRAM and 4 MB onboard Flash memory. Built-in 2.4 GHz Wi-Fi capabilities ensure reliable wireless connectivity, while advanced hardware-level security mechanisms like secure boot, Flash encryption, and digital signatures protect your intellectual property and connected networks.

This kit comes complete with essential assembly accessories including male headers, female headers, and an HY2.0-4P connector for immediate breadboard prototyping or surface-mount integration. Engineered with a high-temperature-resistant housing, the Stamp-C3 withstands SMT reflow temperatures up to 230°C. With an onboard 5V-to-3.3V DC-DC converter, user-programmable RGB LED, programmable push button, reset switch, and 13 multi-function GPIO pins, this versatile module provides complete functionality for industrial automation, smart home systems, and compact IoT projects.

Key Features:

  • RISC-V Microcontroller Core: Powered by a 32-bit RISC-V single-core ESP32-C3 processor running at up to 160 MHz with 400 KB SRAM and 4 MB Flash.
  • Integrated Wireless Connectivity: Features an onboard 2.4 GHz Wi-Fi system coupled with a high-performance 3D antenna for reliable signal transmission.
  • Flexible Mounting Options: Supports multiple deployment formats including surface-mount technology (SMT), dual in-line package (DIP), and flying-lead setups.
  • Onboard Power & I/O: Integrates a built-in 5V-to-3.3V DC-DC step-down circuit, USB Type-C interface, and 13 accessible GPIO pins.
  • User Controls & Indicators: Includes 1 user-programmable button, 1 hardware reset button, and 1 programmable RGB status LED.
  • Heat-Resistant Shielding: Protected by a high-temperature plastic shell capable of enduring SMT reflow soldering temperatures up to 230°C.
  • Multi-Platform Compatibility: Supports rapid software development via Arduino IDE, ESP-IDF framework, and PlatformIO environments.

Applications:

  • Smart home automation devices and wireless sensor networks.
  • Compact Internet of Things (IoT) edge controllers and data loggers.
  • DIY electronics prototyping and embedded systems development.
  • Industrial monitoring, remote telemetry, and smart metering nodes.

Package Includes:

  • 1 x Stamp-C3
  • 1 x High-temperature-resistant sticker
  • 1 x 2.54-12P female header
  • 1 x 2.54-12P male header
  • 1 x 2.54-10P female header
  • 1 x 2.54-10P male header
  • 2 x HY2.0-4P female connector (90°)
  • 1 x L-shaped 1.5mm hex wrench (compatible with M2 screws)
