Name: LIS3MDLTR - Utralow-Power Digital Output Magnetic Sensor LGA-12
Brand: STMicroelectronics
SKU: 033-LIS3MDLTR
Price: 666.09 INR
Availability: InStock

Technical Specifications

Brand:

STMicroelectronics

Case/Package:

LGA

Contact Plating:

Gold

Mount:

Surface Mount

Number of Pins:

Axis:

X, Y, Z

Max Operating Temperature:

85 C

Max Supply Current:

270 uA

Max Supply Voltage:

3.6 V

Min Operating Temperature:

-40 C

Min Supply Voltage:

1.9 V

Number of Circuits:

Operating Supply Voltage:

2.5 V

Output Type:

Digital

Resolution:

2 B

Sensing Method:

Magnetic

Temperature Grade:

Industrial

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:
Datasheet

Ultra Low Power 3 Axis Digital Magnetic Sensor For Compass And Magnetometer Applications

The LIS3MDLTR Ultra Low Power Digital Magnetic Sensor is a high-performance 3-axis magnetometer designed for accurate magnetic field measurement, electronic compass systems, and motion-aware applications. Featuring selectable magnetic full-scale ranges of ±4, ±8, ±12, and ±16 gauss, the sensor provides flexible magnetic field detection for a wide range of consumer, industrial, and portable electronic devices. Its 16-bit digital output ensures high-resolution measurements for precise heading and orientation calculations.

Designed for low-power operation, the LIS3MDLTR supports continuous measurement, single-conversion, low-power, and power-down modes to optimize energy consumption in battery-powered devices. The integrated self-test function, interrupt generation capability, and support for both I2C and SPI communication interfaces simplify system integration. Housed in a compact LGA-12 package, the sensor operates reliably across temperatures from -40 C to +85 C, making it suitable for demanding environmental conditions.

Key Features

3 Axis Magnetic Field Sensing: Measures magnetic fields along X, Y, and Z axes.
Ultra-Low-Power Operation: Optimized for battery-powered and portable devices.
Selectable Magnetic Ranges: Supports +/-4, +/-8, +/-12, and +/-16 gauss full-scale settings.
High Resolution Output: 16-bit digital magnetic field data.
I2C and SPI Interfaces: Flexible communication options for embedded systems.
Interrupt Generator: Supports programmable magnetic field detection events.
Self-Test Function: Enables verification of sensor operation in the final application.
Multiple Operating Modes: Continuous, single-conversion, low-power, and power-down modes.
Independent IO Supply: Supports 1.8 V IO operation.
Wide Supply Voltage Range: Operates from 1.9 V to 3.6 V.
Compact LGA Package: Suitable for space-constrained designs.
RoHS and ECOPACK Compliant: Environmentally friendly design.
