Technical Specifications
Brand:
STMicroelectronics
Case/Package:
SO
Mount:
Surface Mount
Number Of Pins:
8
Number of Terminals:
8
Accuracy:
1 %
Dropout Voltage:
1.1 V
Input Bias Current:
5 mA
Max Input Voltage:
15 V
Max Junction Temperature (Tj):
125 C
Max Operating Temperature:
125 C
Max Output Current:
1.3 A
Max Power Dissipation:
12 W
Max Supply Voltage:
15 V
Min Input Voltage:
4.75 V
Min Operating Temperature:
0 C
Min Output Voltage:
3.3 V
Nominal Supply Current:
5 mA
Number of Channels:
1
Number of Circuits:
1
Number of Outputs:
1
Number of Regulators:
1
Output Current:
800 mA
Output Type:
Fixed
Output Voltage:
3.3 V
Output Voltage Accuracy:
1 %
Packaging:
Tape and Reel
Polarity:
Positive
Power Dissipation:
12 W
Quiescent Current:
5 mA
Voltage Tolerance:
2 %
Height:
1.75 mm
Length:
4.9 mm
Terminal Pitch:
1.27 mm
Width:
3.9 mm
