JETCORE FC: AI-ready Flight Controller Board for Robotics, Drones, AI-edge Computing

VECROS

No reviews yet Write a Review
SKU:
526-JETCORE-FC
MPN:
JETCORE-FC
JETCORE-FC Flight Controller Board – AI-Ready Integrated Drone and Robotics Control Board with NVIDIA Jetson Support
JETCORE-FC Flight Controller Board integrates JetCore Carrier and Cube Flight Controller. AI-ready, rugged, and feature-rich with NVIDIA Jetson support, NVMe expansion, IMUs, and PX4/ArduPilot compatibility. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹104,428.82 inc. GST
₹88,499.00 ex. GST

Technical Specifications

Brand:
VECROS
Comptability:
NVIDIA Jetson Xavier NX, Orin NX, Orin Nano
Power Input:
XT30 Connector, up to 6S LiPo (25.2V max)
Interfaces:
Ethernet, USB, SPI,CAN,UART,GPIO,PWM
Video Output:
Micro HDMI 2.0 (up to 4K)
Storage Expansion:
1 x M.2 Key-M slot for NVMe SSD
IMUs:
Triple redundant IMUs with vibration isolation
Power Input:
25.2V Max

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

JETCORE-FC Flight Controller Board – Advanced Integrated AI-Ready Flight Control System: Reliable performance for drones, robotics, and industrial UAV applications

The JETCORE-FC Flight Controller Board is a next-generation, all-in-one flight control and computing platform that merges the capabilities of the JetCore Carrier Board with the Cube Flight Controller. Designed for drones, autonomous robotics, and AI edge computing, it provides high-performance real-time processing, robust connectivity, and precise control in a rugged compact form factor. With compatibility for NVIDIA Jetson Xavier NX, Orin NX, and Jetson Nano modules, it supports JetPack 4.x and 5.x (LTS), making it an AI-ready platform for mission-critical applications.

Built for reliability, the JETCORE-FC withstands extreme temperatures from -40°C to +85°C, making it ideal for industrial, defense, and outdoor environments. It integrates dual BMI088 IMUs for motion and environmental monitoring, includes a Crypto Auth IC for data security, and supports multiple industry-standard flight software such as QGroundControl (QGC), Mission Planner, ArduPilot, and PX4.

Key Features:

  • Integrated Design: Combines JetCore Carrier Board and Cube Flight Controller for seamless performance.

  • AI-Ready Platform: Optimized for NVIDIA Jetson Xavier NX, Orin NX, and Jetson Nano with support for JetPack 4.x & 5.x (LTS).

  • Comprehensive Connectivity:

    • 1 × USB 3.0 (FPC Type)

    • 6 × USB 2.0 (FPC Type)

    • 1 × USB 2.0 (Micro USB for Debugging)

    • 1 × Gigabit Ethernet (RJ45)

    • 1 × Micro HDMI 2.0 (up to 3840 × 2160 resolution)

    • 12-lane CSI-MIPI (via Daughterboard Connector)

    • 2 × SPI, 1 × CAN, 1 × I2C, 1 × UART (all JST GH connectors)

    • GPIO and PWM support

  • Storage Expansion: M.2 Key M interface for NVMe SSD + SD card slot.

  • Environmental Monitoring: Dual BMI088 IMUs for precise motion and temperature sensing.

  • Security: Integrated Crypto Auth IC for enhanced data protection.

  • Power Input: Wide 5V–25V DC range for flexible deployment.

  • Rugged Durability: Operational in extreme -40°C to +85°C environments.

  • Software Compatibility: Works with QGroundControl (QGC), Mission Planner, ArduPilot, and PX4 for versatile flight management.

Package Content:

• 1 x Jetcore Flight Control Board
• 1 x Power Cable
