Gravity: Laser PM2.5 Air Quality Sensor For Arduino

DFRobot

No reviews yet Write a Review
SKU:
147-SEN0177
MPN:
SEN0177
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹5,366.64 inc. GST
₹4,548.00 ex. GST
5 people looking at this.

Technical Specifications

Brand:
DFRobot
Target Gas:
Air Quality

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

The PM2.5 laser dust sensor is an advanced digital particle concentration sensor capable of measuring the quantity of suspended particulate matter in a given volume of air ranging from 0.3 to 10 microns. It accurately determines the concentration of particulate matter and provides digital output through its interface. Additionally, it can also deliver data on the quality of individual particles. These sensors are versatile and can be integrated into various environmental instruments to monitor and report real-time concentration data of suspended particulate matter in the air, ensuring timely and precise measurements.

Gravity: Laser PM2.5 Air Quality Sensor For Arduino

Specification
  • voltage: 4.95 ~ 5.05V
  • Maximum electric current: 120mA
  • Measuring pm diameter: 0.3~1.0/1.0~2.5/2.5~10 (um)
  • Measuring pm range: 0~1000 ug/m3
  • Standby Current: <=200 uA
  • Response time:  <=10 s
  • Operating temperature range:  -20 ~ 50C
  • Operating humidity range: 0 ~ 80Percent RH
  • Maximum size: 46 x 35 x 20mm (1.82 x 1.38 x 0.79 inches)
  • MTBF: > = 5 years
Package Contents
  • PM2.5 laser dust sensor x1
  • PM2.5 sensor adapter x1
  • sensor adapter cable x1
