G6QE-1A DC12 - 12V 36A 1FormA High Power Relay Through Hole 30.5x16mm

Omron Electronics

No reviews yet Write a Review
SKU:
169-G6QE-1A-DC12
MPN:
G6QE-1A DC12
G6QE 12V 36A SPST normally open high power relay through hole 30.5x16mm PCB relay for heavy load switching
Quantity
Unit Price (ex. GST)
1 - 9
₹ 494.22
10 - 99
₹ 469.51
100 or above
₹ 444.80
12V 36A SPST (1 Form A) ultra high power relay with through-hole mounting. Ideal for heavy load switching in industrial automation and appliances. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹583.18 inc. GST
₹494.22 ex. GST

Technical Specifications

Brand:
Omron Electronics
Package:
Through Hole
Contact Material:
Silver Alloy (Cd-Free)
Coil Voltage:
12V
Number of Pins:
4
Operating Temperature:
-40 C~+60 C
Release Time:
10ms
Operate Time:
20ms
Switching Current(Max):
36A
Contact Form:
1 Set Normally Open: 1A (SPST NO)
Size:
30.5x16mm
Coil Resistance:
102.9Ohm
Contact Resistance:
100mOhm

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:
Datasheet

Ultra High Current 12V 36A SPST (1 Form A Normally Open) Through Hole Relay for Heavy Load Power Switching

The G6QE 12V 36A 1 Form A high power relay is a high-performance electromechanical relay engineered for demanding applications requiring reliable high-current switching. Operating with a 12V DC coil, this relay supports up to 36A switching capacity and features an SPST (Normally Open) configuration, making it ideal for direct ON/OFF control of high-power loads such as compressors, industrial heaters, inverters, and power distribution systems. Its compact yet powerful design makes it suitable for both industrial automation and high-load consumer electronics.

Designed in a low-profile through-hole package (~30.5x16mm), the G6QE series delivers exceptional electrical performance with high insulation strength (~10kV impulse withstand) and durable silver alloy contacts. It offers stable switching with long electrical life (~100,000 operations at rated load) and efficient coil management (~1.4W), ensuring reliable operation even in harsh environments. The relay is widely used in home appliances, factory automation equipment, and industrial machinery where high current handling and compact PCB integration are critical.

Key Features

  • 36A High Switching Capacity: Designed for heavy-duty power loads
  • 12V DC Coil Voltage: Compatible with industrial control systems
  • SPST (1 Form A): Normally Open configuration for simple switching
  • Compact High-Power Design: ~30.5mmx16mm footprint
  • Through Hole Mounting: Strong and reliable PCB installation
  • High Surge Withstand: Up to ~10kV impulse voltage
  • Low Contact Resistance: ≤100mΩ for efficient conduction
  • Durable Contacts: Silver alloy for long operational life
  • Wide Operating Temperature: -40 C to+85 C
