G6B-2214P-US-DC12 - 12V 5A 2FormA High Power Relay Through Hole 19.9x10.9mm

Resources:
Datasheet

12V 5A DPST (2 Form A Normally Open) Through Hole Relay for Dual Load Switching in PCB and Automation Systems

The G6B 12V 5A 2 Form A high power relay is a subminiature electromechanical relay designed for efficient dual-circuit switching in compact electronic systems. Operating with a 12V DC coil, this relay supports up to 5A switching per contact and features a DPST (2 Form A Normally Open) configuration, enabling simultaneous control of two independent loads. It is widely used in PLC interfaces, control panels, instrumentation, and embedded automation where coordinated switching is required.

Engineered with a slim through-hole PCB mount design (~19.9x10.9mm), the G6B series offers low power consumption (~200mW), high dielectric strength, and reliable switching performance. The relay incorporates a moving loop armature design that reduces contact bounce and improves operational stability. With support for up to 250V AC / 30V DC switching and impulse withstand up to ~6kV, it ensures safe and long-term operation in industrial environments.

Key Features

• 5A Switching Capacity: Suitable for control and moderate load switching
• 12V DC Coil Voltage: Compatible with automation and embedded systems
• DPST (2 Form A): Dual normally open contacts for simultaneous switching
• Compact Design: ~19.9mmx10.9mm footprint for dense PCBs
• Low Power Consumption: ~200mW coil for energy-efficient operation
• Through Hole Mounting: Reliable PCB integration
• High Dielectric Strength: Up to ~6kV impulse withstand
• Durable Contacts: Silver alloy for long operational life
• Fast Switching Performance: ~10ms operate and release time
