Technical Specifications
Brand:
Radxa
SoC:
Rockchip RK3576 or RK3576J
CPU:
Quad‑core Cortex‑A72 (1MB L2) and Quad‑core Cortex‑A53 (512KB L2) ARMv8‑A, TrustZone, Cryptography Extensions
GPU:
ARM Mali G52 MC3
NPU:
6 TOPS (INT8), supports INT4/INT8/INT16/FP16/BF16/TF32 compatible with TensorFlow, PyTorch, ONNX, etc.
Memory:
LPDDR4/LPDDR4X (up to 4266MT/s) dual‑channel 16bit, up to 16GB total address space
Codec:
H.264 multivideo decoder up to 4K 60fps,H.265 multivideo encoder up to 4K 60fps
Storage:
Onboard eMMC Up to 256GB,
Storage Optional onboard SPI Flash:
1x UFS 2.0 ,1x SDMMC
Ethernet:
1x Onboard Gigabit Ethernet PHY supporting IEEE 1588
Video Input:
1x 4‑lane MIPI CSI,1x 4‑lane MIPI CSI or 2x 2‑lane MIPI CSI
Video Output:
1x HDMI TX up to 4K 120Hz,1x 4‑lane eDP Interface up to 4K60fps,1x DP Interface up to 4K 120fps,1x 4‑lane MIPI DSI for MIPI LCD,Able to provide 2x display output
USB:
1x USB 3.2 Gen1x1 OTG / HOST,1x USB 3.2 Gen2x1
PCIe:
2x PCIe Gen2 1‑lane
Low Speed Buses:
SPI, I2C, I3C, UART, CAN
Operation Temperature:
0C to 60C(Commercial Grade) ‑40C to 85C(Industrial Grade)
