Understanding the Role of HMI in Industrial Systems

• HMI (Human-Machine Interface) is crucial for operator interaction with industrial systems.

• It enhances efficiency by providing real-time data and control.

• Effective HMIs improve safety and reduce errors in operations.

• Design considerations include usability, accessibility, and feedback mechanisms.

What is a Human Machine Interface (HMI)?

Human Machine Interface (HMI) represents the hardware or software that lets operators interact with controllers. These interfaces act as vital links between human operators and industrial machines, systems, and processes. The technology has evolved substantially from its basic pushbuttons and indicator lights in the 1980s into something more compact and adaptable.

NIST describes HMI as anything from a basic control panel with buttons and lights to an industrial PC that runs specialized software with color graphics display. Today's HMIs come in various sizes, ranging from standard 4.3-inch devices to advanced widescreen 15.6-inch displays based on specific industrial needs.

The technology uses several input methods:

• Touchscreens (capacitive or resistive)

• Physical keypads and buttons

• Graphical user interfaces (GUIs)

Modern HMIs go beyond simple monitoring. They give plant staff an easy-to-use way to work with complex processes and see data that would otherwise need constant equipment checks.

HMI Meaning in Automation

The HMI in automation contexts means more than just hardware—it's a complete system that turns complex data into clear information. These interfaces bridge the gap between operators and machines by showing visual representations of industrial processes.

The system displays live data, status updates, alarms, and control options that let operators monitor and control machinery effectively. A well-designed interface strengthens operators' abilities by showing complex information through simple graphs, charts, and color-coded indicators.

Good HMI systems bring clear advantages. Operators feel more confident, material waste drops, downtime shrinks through better diagnostics, and product quality improves with closer parameter monitoring. These systems have grown more capable over the last several years. They now handle calculations, track alarms, and create reports that previously needed PLCs and other control devices.

How HMIs Interact with PLCs and Sensors

HMIs and Programmable Logic Controllers (PLCs) work together through integrated hardware and software components. This connection creates the foundation of today's industrial automation systems.

PLCs and sensors gather data from the production floor. The HMI software processes this information and creates visual displays of the automation system—including screens, data views, and interactive elements like buttons and input fields.

Operators use the HMI's interface to watch processes, adjust settings, handle alarms, or start sequences. The system sends these commands to the PLC. Data flows both ways through several communication protocols:

• Modbus

• Ethernet/IP

• PROFINET

• OPC-UA

• RS232/RS485

• UART/TTL

The HMI and PLC systems can both trigger alerts. Operators see these notifications on the HMI screen, which shows important details about faults or unusual conditions the PLC detects. The HMI helps operators solve problems by providing detailed system information, error logs, and diagnostic tools.

A soda manufacturer shows the practical benefits of this technology. They upgraded to a modern 10.1" HMI and cut their monitoring delay from 15 seconds to 0.2 seconds. This improvement led to 18% fewer errors and 12% higher output.

---

Quick Selection Guide (by scenario):

Before you dive into the guide, here’s the quick why: engineers don’t buy “displays,” they buy fit—the right size, interface, touch tech, brightness, and enclosure for the job. Evelta’s range spans compact OLEDs and e-paper for ultra-low-power status panels, SPI/I²C and RGB/TTL LCDs for MCU workflows, UART/RS232/RS485 HMIs for fast DGUS-based UIs, and plug-and-play HDMI + USB touch (plus Android HMI options) for Raspberry Pi, gateways, and kiosks—curated for practical buildability with readily available accessories.

The Quick Selection Matrix below maps common scenarios to in-stock picks, but it’s a starting point, not a spec sheet: brightness (nits) vs. ambient light, glove compatibility, IP/NEMA ratings, EMC, temperature derating, protocol needs, firmware/tooling, and certification can change the right answer—and SKUs evolve. Please read the rest of this guide for deeper criteria and trade-offs, before you lock your choice.

Scenario / Need	Host & Interface	Size / Resolution	Touch	Key Requirements	Evelta pick(s)	Why this pick
Budget serial HMI for basic UI	MCU / PLC — UART (TTL/RS232)	4.3″ • 480×272	Capacitive	Low costDGUS readyFast to deploy	DWIN 4.3″ HMI (CTP, TTL/RS232)	Great entry point; built-in DGUS II shortens UI dev, keeps BOM tight.
Mid-range serial HMI with more layout room	MCU / PLC — RS232	7.0″ • 800×480	Resistive	Larger UISD assetsBuzzer	DWIN 7″ HMI (RTP, RS232)	Common 7″ form factor; easy migration path from 4.3″ projects.
Industrial HMI with enclosure (panel-mount)	PLC / Gateway — RS232/RS485	7.0″ • 800×480	—	Panel mountField-readyRS485	DWIN 7″ HMI with Shell (RS232/RS485)	Integrated bezel/shell simplifies installation and protects the module.
High-res dev / Android kiosk	App / Edge — Android 11	7.0″ • 800×1280	Capacitive	App UXWi-Fi/BTFast POC	DWIN 7″ Android 11 Display	All-in-one SoC + touch; ideal for kiosks, signage, and rich UI protos.
Large format serial HMI (production)	MCU / PLC — TTL/RS232	10.1″ • 1024×600	Capacitive	Wide viewDGUS IIBuzzer/SD	DWIN 10.1″ HMI (CTP, TTL/RS232)	Mature 10.1″ platform; comfortable space for complex HMI screens.
Raspberry Pi / PC dashboard (plug-and-play)	Pi / PC — HDMI + USB touch	10.1″ • 1280×800	Capacitive	Driver-freeCaseIPS	Waveshare 10.1″ HDMI (with case)	Drop-in monitor for Pi/PC dashboards; toughened glass & stand.
Color-critical demos / multimedia	Pi / PC — HDMI/Type-C	13.3″ • 1920×1080	Capacitive	High PPIWide color	Waveshare 13.3″ FHD (with case)	Great color and clarity for sales demos or HMI UX reviews.
Round / compact UI or meters	MCU — RGB/TTL	4.0″ • 480×480 (round)	Capacitive	Modern lookSmall footprint	DWIN 4.0″ 480×480 Round (CTP)	Eye-catching round UI for dials, gauges, wearables, compact panels.
Ultra-low-power signage / labels	MCU — SPI	4.2″ • 400×300	—	E-Paper Readable in sun Battery-friendly	Waveshare 4.2″ E-Ink Module	Perfect where power budgets are tight and static content dominates.

---

Key Types of HMI Displays and Their Use Cases

HMI displays come in many forms. Each one serves a unique operational need. You'll make better choices for your industrial applications by knowing the differences between HMI types. Let's look at the main categories and how they work in practice.

Basic Text-Based HMIs for Simple Monitoring

Text-based HMIs stand as the simplest type of HMI. These displays show information through text with alphanumeric characters. You'll find monochrome screens that display process data, status messages, and navigation options. Delta's Text Panel series shows how these systems work. It turns program codes into text and graphical displays while working with different communication protocols.

You'll spot these interfaces in:

• Legacy industrial systems where graphics aren't needed

• Budget-conscious projects that need simple monitoring

• Tough industrial settings where graphical displays might not work well

Text-based HMIs might not show complex data well, but they're incredibly reliable and easy to maintain. The TP02G-AS1/TP04G-AS2 Series comes with STN LCD displays (2.8" and 3" respectively). These units pack multiple function keys and support both RS-232 and RS-485 ports. Their simplicity makes them valuable tools in many industrial settings, thanks to their toughness and economical benefits.

Advanced Graphic HMIs with Touchscreen Support

Graphic HMIs take a big leap forward from text-based interfaces. They create user-friendly visualization through icons, buttons, and dynamic diagrams. Colors, shapes, and animations make system data more interactive, which helps operators process information faster.

Today's graphic HMIs use either resistive or capacitive touchscreen technology. Resistive touchscreens use multiple layers with small gaps between flexible sheets. This design makes them tough against dust and water while giving precise control. Capacitive touchscreens work differently. They use glass overlays with embedded electrodes to detect touch. This technology allows better sensitivity and multi-touch gestures that users expect in modern interfaces.

Red Lion's Graphite operator panels show what advanced graphic HMIs can do. These rugged aluminum units come in sizes from 7 to 15 inches. Users get drag-and-drop protocol conversion, data logging, and web monitoring features. Plus, they meet UL Class 1, Division 2 standards for tough environments.

Mobile and Web-Based HMIs for Remote Access

Remote monitoring solutions have pushed mobile and web-based HMI systems forward. Operators can now control industrial processes from anywhere using standard web browsers or mobile devices.

Web Panel HMIs now include HTML5 support for web server applications. This feature lets you monitor and control systems remotely through regular browsers. AVEVA offers web-based HMI solutions that let you monitor securely beyond the industrial network with mobile-ready dashboards. The OAS Web HMI fits right into existing web applications using common browser standards like HTML, JavaScript, and CSS.

These systems bring major benefits:

• Up-to-the-minute monitoring from any connected device

• Fewer operators needed on-site

• Updates managed from one place

• Better security through user controls

Embedded HMIs in Dedicated Equipment

Machinery and control systems often use built-in embedded HMIs. Unlike regular computers running HMI software, these systems focus solely on operational technology tasks. This specialized design makes them efficient and light on computing resources.

Tough field conditions don't stop these interfaces. Their compact, strong design and special components handle harsh environments well. Omron's NB Series gives machine builders economical HMI options from 3.5 to 10.1 inches. These units work in portrait or landscape mode to fit tight spaces.

Embedded HMIs cost less than PC-based options. They ship with runtime software, need simpler licenses, and use all-in-one designs that break down less often. Many now support "headless" operation, where mobile devices handle visualization while core functions keep running.

---

Essential Criteria for Choosing the Right HMI

Your industrial application needs the best HMI. Several key factors will determine if your system performs at its best. You need to look at physical features, environmental conditions, interface types, and how well it displays information.

Requirement	Minimum spec / decision rule	Why it matters	Example Evelta options
Mounting & mechanics	Pick size that fits panel cutout and ergonomics: 4.3–5″ (tight spaces), 7″ (standard panels), 10.1–15.6″ (complex UIs).	Avoid rework on enclosures; ensures readable UI density.	4.3″ 480×800 PCAP, RGB/TTL · 5.0″ 800×480 PCAP HMI, TTL/RS232 · 7.0″ 800×480 RS232 HMI, resistive
Environment	Match SKU’s stated operating range to site (e.g., indoor kiosks 0…+50 °C; factory/field often −20…+70 °C on industrial HMIs).	Prevents washouts/freezes & early failures.	DWIN DGUS HMI family · Example datasheet (temperature/specs)
Ingress (front)	Indoor: IP54; dusty/splash: target IP65 front via bezel + gasket; washdown: IP66/67 with proper enclosure.	Keeps liquids/particulates out; protects touch.	7″ HMI with shell (panel-friendly)
Readability / optics	Indoor: ≥300 nits; bright shop floor: ≥500–600 nits; outdoor/sunlit: ≥1,000 nits or transflective.	Ensures legibility in ambient light.	7″ 1024×600 HDMI IPS, PCAP
Touch / HMI mode	Gloves/EMI/grease → resistive. Gestures/multi-touch → PCAP. Add hard keys for e-stops.	Usability & safety.	7″ RS232 resistive HMI · 3.0″ PCAP HMI (compact)
I/O & connectivity	Legacy PLCs → RS-232/485 (Modbus RTU). Modern PLC/Ethernet devices → Ethernet-IP/Modbus TCP (via HDMI/host SBC) or TTL to host MCU.	Matches plant network & tag counts.	RS-232/485 7″ HMI · 4.3″ TTL/RS-232 HMI
UI complexity & performance	Trend charts, alarms, multi-screens → ≥800×480; video/desktop mirroring → HDMI class; simple keypads → 320×240+.	Fits information density and frame rates.	4.3″ 480×800 DGUS II HMI · 7″ 800×480 RS232 HMI · 7″ 1024×600 HDMI PCAP
Toolchain & dev flow	Prefer DGUS II smart LCMs for rapid GUI authoring; use HDMI panels when you already have an OS/SBC.	Reduces time-to-HMI and firmware risk.	DGUS II-based DWIN HMIs (category)
Lifecycle & service	Favor parts with clear datasheets, stock & accessories (cables/SD/FFC).	Simplifies sustaining engineering.	DWIN family · LCD/OLED/Graphic displays (category)

Display Size and Resolution Requirements

The right display size needs to balance visibility, ergonomics, and space limits. Operators like bigger screens because they can see them from far away. These screens also show more information at once without extra scrolling. Space for mounting and costs often limit your size options, especially at good working heights.

Simple monitoring tasks with limited data work fine with smaller 4.3-inch screens. Complex applications that need detailed graphics work better with 7-inch or larger displays with better resolution. Screen resolution makes a big difference in image quality and clarity. This matters a lot when you're showing complex process data. You must measure precisely to fit existing cutouts.

Environmental Ratings: IP65, NEMA Standards

The environment where you use your HMI plays a big role in picking the right one. Industrial HMIs must handle water, chemicals, extreme temperatures, and other tough conditions. Protection ratings are vital here.

IP (Ingress Protection) ratings use two numbers. The first shows protection from solids (1-6), and the second from liquids (1-9). Take IP65 - it means the case keeps out all dust (6) and handles low-pressure water jets (5). NEMA standards are big in North America. They look at more things like how well it fights rust, how it's built, and how gaskets age.

Food processing plants need devices with high IP ratings (IP65/IP67) because they get washed down often. Outdoor screens need to be readable in daylight and work in different temperatures.

Touchscreen vs Physical Button Interfaces

Your choice between touchscreens and physical buttons depends on what operators need and where they work. Resistive touchscreens feel pressure and work with gloves or styluses - perfect for industrial settings. Capacitive screens are more sensitive and handle multiple touches but usually need bare fingers.

Physical buttons give you:

• Feedback you can feel without looking

• Better control with thick gloves

• More reliable performance around water or dust

Touchscreens let you do more things and are easy to use with adaptable interfaces. Studies show that touchscreen feedback brings out better emotional responses than physical buttons, especially with the right touch feel.

Real-Time Data Visualization Capabilities

Good HMI systems must show process data clearly and quickly. A soda maker showed this by upgrading their HMI. They cut their monitoring delay from 15 seconds to 0.2 seconds.

What you need to see depends on how complex your application is. Simple apps might just need status lights. Complex processes work better with trend displays, alarm systems, and data logging. These HMIs need enough memory (at least 4MB RAM plus compact flash card access) to handle lots of data.

The most important thing is that your HMI's display features match what your industry needs. Operators should see critical information exactly when and where they need it.

Now, let’s turn above rules into two quick, real-world builds.

---

---

Communication Protocols and System Compatibility

Your HMI's communication with other industrial components are the foundations of any successful automation system. The right protocols will give you seamless data exchange and compatibility throughout your industrial network.

Modbus, Ethernet/IP, and Profibus Support

Several key protocols dominate the industrial world, each bringing unique advantages to specific applications. Modbus, which Modicon created in 1979, stands as one of the most common protocols because it's simple and follows open standards. The system works through a master-slave setup where your human machine interface usually acts as the master, while sensors and PLCs serve as slaves. Though not the fastest choice, its widespread use makes it perfect to connect equipment of all types.

Ethernet/IP brings the Common Industrial Protocol to standard Ethernet and creates smooth enterprise connectivity. This protocol shines in high-performance environments like automotive manufacturing because it can move large amounts of data at once. Its design supports backup systems that keep operations running even if network paths fail.

Profibus, which European industries prefer, emerged in the late 1980s and still powers industrial automation today. The protocol delivers rock-solid real-time communication that industries need for precise control and quick responses.

HMI-PLC Compatibility Considerations

Your HMI system must work with your existing programmable logic controllers. Both devices should support similar communication settings like baud rate, parity, and data bits. Your HMI should read entire registers instead of individual boolean data—this matters a lot when you monitor bit-level information.

Small machine applications work well with modern HMIs as standalone systems with proper configuration. Many controllers start in RUN mode and work right away without needing user activation from the interface.

Integration with SCADA and MES Systems

Man machine interfaces usually work as part of bigger SCADA systems that boost factory productivity. Your industrial ecosystem needs strong connections between all components—PLCs, RTUs, and distributed control systems included.

A successful SCADA setup starts with listing all your factory's industrial processes and daily systems. This list should cover ERP systems and everything that handles maintenance, quality, process control, or equipment performance. Networks that connect these systems help you see and improve your operation's productivity.

Your HMI choice should fit both today's needs and tomorrow's growth. Smart designs might add support for Industrial IoT systems, including MQTT protocol compatibility. This approach keeps your interface relevant as technology moves forward.

---

Emerging Trends in HMI Technology

Manufacturers are changing how they approach information visualization, connectivity, and user interaction in HMI technology. These new developments want to improve operator effectiveness and handle increasingly complex industrial systems.

High-Performance HMI Design Principles

High-performance HMI design creates interfaces that show critical information clearly so operators can make better decisions faster. Traditional interfaces often overwhelm operators with complex visuals and too many colors. Modern designs focus on situational awareness through useful information. These interfaces use muted grayscale backgrounds to cut down glare and operator fatigue. Colors appear only to highlight unusual situations.

The ISA-101 HMI Design Standard from 2015 gave a vital framework to develop these systems. The focus has now moved toward making operators more efficient and creating screens that boost situational awareness. Good implementations follow key principles:

• Analog indicators replace numerical displays

• Trend visualization comes first

• Equipment detail drawings stay minimal

• Process flow stays consistent (left to right)

High-performance HMIs use a four-tier display system for complex operations. Level 1 shows system overview, Level 2 covers specific process units, Level 3 displays equipment details, and Level 4 presents diagnostic screens. This layout helps operators see everything while reducing screen monitoring work.

Cloud-Connected and Edge-of-Network HMIs

Cloud connectivity has changed how industrial companies get plant data. Managers, engineers, and technicians can now access information whenever they need it. These systems work with many communication platforms—TCP/IP, Direct SQL, and OPC UA—and connect smoothly with existing control systems.

Edge computing solves common problems by combining multiple software solutions into single platforms. Old systems needed separate computers for HMI/SCADA software, historians, and other applications. Edge computing with built-in virtualization makes this setup simpler. The benefits include:

• Built-in redundancy prevents unexpected downtime

• Simple management reduces security risks

• Fewer hardware assets mean less maintenance

• Remote or hazardous environments get more reliable systems

Mission-critical operations benefit most from these platforms. The setup looks like a Gartner Edge Computing topology—an edge version of the traditional Purdue Model for industrial control systems.

AR/VR Interfaces for Industrial Visualization

AR brings major improvements to HMI/SCADA by offering new ways to collect and show data meaningfully. AR doesn't replace traditional interfaces but adds features that help operators work better.

Industrial AR interfaces work through industrial-grade tablets or hands-free goggles. These devices overlay virtual interfaces onto ground assets. This creates several advantages:

• Maintenance becomes easier with step-by-step guides and instant access to manuals

• New employees learn faster through guided procedures

• Operators can safely access data behind safety barriers

AR systems need strong edge processing power and AI services that identify objects through image analysis. Boeing's AR interface cut aircraft assembly errors by 50% and reduced assembly time by 25%. AR combined with digital twin technologies shows promise across manufacturing systems and product lifecycles.

---

Conclusion

Don’t overthink it: match environment → choose interface → confirm touch. Our Quick Selection Guide, Essential Criteria table, and Worked Examples cover most Indian factory floors. For edge cases or bulk orders, drop us a note at sales@evelta.com - we’ll recommend a fit and share stock plans. Most items ship within 24 hours from Mumbai.

---

FAQs

Q. What is an HMI and why is it important in industrial systems?

A. An HMI (Human Machine Interface) is a hardware or software interface that allows operators to interact with and control industrial machines and systems. It's crucial for monitoring processes, visualizing data, and enabling efficient decision-making in industrial environments.

Q. How do I choose the right display size for my HMI?

A. The ideal display size depends on your specific application. Consider factors like the amount of information to be displayed, viewing distance, and available mounting space. Larger screens (7-inch or more) are better for complex applications, while smaller screens (4.3-inch) may suffice for basic monitoring.

Q. What are the key differences between touchscreen and physical button interfaces?

A. Touchscreens offer greater flexibility and intuitive interaction, while physical buttons provide tactile feedback and are easier to use with gloves. Resistive touchscreens work well in industrial environments, while capacitive screens offer multi-touch capabilities but require bare skin contact.

Q. How important are environmental ratings when selecting an HMI?

A. Environmental ratings like IP65 and NEMA standards are crucial when choosing an HMI for industrial use. These ratings indicate the device's ability to withstand exposure to dust, water, and other environmental factors, ensuring reliability in harsh conditions.

Q. How bright should my HMI be for Indian shop floors and kiosks?

A. Use ambient light as your anchor:

• Control room / office: 250–350 nits
• Bright shop floor (LED bay lights, glossy surfaces): 500–700 nits
• Semi-outdoor / shaded concourse: 600–800 nits
• Outdoor / near windows / sunlit: ≥1,000 nits or transflective (plus anti-reflective glass)

Tips: Prefer IPS (wide viewing angles), consider optical bonding (cuts internal reflections), add matte/AR glass for glare, and keep PWM/brightness control for night shifts.

Q. Do I need RS-232 or RS-485 for my PLC?

A. Quick rule of thumb:

• Distance & noise:
  • RS-232 → short runs (≤15 m), point-to-point, more noise-sensitive.
  • RS-485 → long runs (up to hundreds of meters), multi-drop (many nodes), great noise immunity.
• Topology:
  • RS-232: 1-to-1 (TX/RX/GND).
  • RS-485: 2-wire A/B (half-duplex) or 4-wire (full-duplex); terminate ends with 120 Ω and add bias where needed.
• Protocols: Both commonly use Modbus RTU. If your system uses Ethernet (Modbus TCP/EtherNet/IP), consider an HDMI/OS-based HMI or a gateway.
• What to check on the PLC/HMI:
  • Labels like “RS-232/COM1” vs “RS-485 A/B” on terminals.
  • If your controller only exposes UART/TTL (3.3/5 V), choose an HMI with TTL or add a level shifter/RS-485 transceiver.

Bottom line: If you’re on a noisy line, need longer cables, or multiple devices on one bus, pick RS-485. If it’s a short, direct connection to one PLC port, RS-232 works and is simpler.

---
