Technical Specifications
Brand:
Diodes Incorporated
Case/Package:
TO-236-3
Contact Plating:
Tin
Mount:
Surface Mount
Number Of Pins:
3
Number of Terminals:
3
Accuracy:
1 %
Dropout Voltage:
250 mV
Max Input Voltage:
13.2 V
Max Junction Temperature (Tj):
125 C
Max Operating Temperature:
125 C
Max Output Current:
300 mA
Min Input Voltage:
6 V
Min Operating Temperature:
-40 C
Number of Channels:
1
Number of Circuits:
1
Number of Outputs:
1
Number of Regulators:
1
Output Current:
300 mA
Output Type:
Fixed
Output Voltage:
5 V
Polarity:
Positive
Quiescent Current:
100 uA
Voltage Tolerance:
2 %
Height - Seated (Max):
1.45 mm
Length:
2.9 mm
Terminal Pitch:
950 um
Width:
1.6 mm
