7.0 Inch 1024x600 HMI LCD Display Capacitive Touch TTL/RS232

DWIN

No reviews yet Write a Review
SKU:
353-DMG10600T070_01WTC
MPN:
DMG10600T070_01WTC
7.0-inch 1024x600 HMI LCD Display with capacitive touch, industrial-grade, featuring IPS-TFT-LCD, 32MB flash, buzzer, RTC, and TTL/RS232 interface.
Quantity
Unit Price (ex. GST)
1 - 9
₹ 3,863.00
10 or above
₹ 3,708.48
The 7.0-inch 1024x600 HMI LCD Display with capacitive touch offers industrial-grade performance with 32MB flash, buzzer, RTC, and TTL/RS232 interface. Ideal for demanding industrial applications, it features IPS-TFT-LCD for vibrant visuals. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹4,558.34 inc. GST
₹3,863.00 ex. GST

Technical Specifications

Brand:
DWIN
Display Size:
7.0 inch
Resolution:
1024x600
Display Panel:
IPS-TFT-LCD
Touch Type:
Capacitive
View Angle:
Wide viewing angle, 85°/85°/85°/85° (L/R/U/D)
Color:
24-8R8G8B
Display Area:
154.2mm (W)x85.9mm (H)
Power Supply:
12V 1A DC
LCM interface:
FPC50_0.5mm, RGB interface
Memory:
32MB
Buzzer:
3V passive buzzer
SD Interface:
FAT32. Download files by SD interface can be displayed in statistics. Download rate: 4Mb/s
PGT05 Interface:
When product crashes by accident, you can use PGT05 to update DGUS kernel and make the product return to normal
Brightness:
250nit
RTC:
Yes
User Interface:
8Pin_2.0mm(RS232),2Pin_2.0mm(RS485)
Interface:
TTL/RS232
Weight:
265g

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

High-Performance 7.0-Inch Industrial-Grade HMI LCD Display: Enhance Your Industrial Applications with Superior Visuals and Functionality

The 7.0-inch 1024x600 HMI LCD Display is designed to meet the demanding needs of industrial applications. With a capacitive touch interface, this display offers a user-friendly experience, delivering crisp and vibrant visuals in 16.7 million colors. Powered by the advanced T5L2 ASIC and running on the DGUS II system, it ensures seamless integration and operation. The IPS-TFT-LCD technology provides a wide viewing angle, making it ideal for diverse industrial environments. Built with conformal coating and industrial-grade components, this display guarantees durability and long-lasting performance.

Key Features:
  • Advanced Visuals: 1024x600 pixels resolution with IPS technology for wide viewing angles and vibrant color reproduction.
  • Capacitive Touch Screen: Responsive touch interface for an enhanced user experience.
  • Robust Connectivity: TTL/RS232 interface with 8Pin_2.0mm connection wire for easy integration.
  • Flexible Development: Supports GUI & OS dual-core system, DGUSⅡ/TA system development, and allows for second development through DWIN OS language or KELI C51.
  • Industrial Grade: Designed with conformal coating for durability and reliability in harsh industrial environments.
