Name: 1206 SMD Bi-Colour LEDs Red 573nm Green 624nm 20mA
Brand: Everlight Electronics
SKU: 012-11-22-R6G6C-A01-2T
Price: 17.62 INR
Availability: InStock

Technical Specifications

Brand:

Everlight Electronics

Case/Package:

1206

Color:

Green, Red, Yellow

Lens Color:

Colorless

Mount:

Surface Mount

Number Of Pins:

Number of Terminals:

Shape:

Rectangular

Dominant Wavelength:

624 nm

Forward Current:

20mA

Forward Voltage:

2 V

Illumination Color:

Green, Red

Lens Style:

Circular, Clear, Colorless, Diffused

Lens Transparency:

Clear

Luminous Intensity:

225 mcd

Max Operating Temperature:

85 C

Min Operating Temperature:

-40 C

Number of Circuits:

Number of Elements:

Number of LEDs:

Power Dissipation:

60 mW

Reverse Voltage:

5 V

Test Current:

20 mA

Viewing Angle:

60 deg

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:

Datasheet

SMD Bi-Colour Red and Green LED for Compact Indicator and Backlighting Applications

The 11-22/R6G6C-A01/2T is a compact SMD bi-colour LED from Everlight, integrating brilliant red and yellow green emitters in a single package. Designed for space-constrained PCB layouts, this LED enables dual-status indication without increasing component count, making it suitable for modern, high-density electronic designs. The device is built using AlGaInP chip technology and housed in a water-clear resin package for clear colour visibility and stable optical performance.

With a typical viewing angle of 60 and reliable luminous output at standard operating current, this bi-colour SMD LED is well suited for dashboard indicators, switch backlighting, and symbol illumination. Its lightweight construction supports automated pick-and-place assembly and compatibility with infrared and vapour-phase reflow soldering. The 11-22/R6G6C-A01/2T is widely used in telecommunications equipment, LCD backlighting, and general-purpose electronic indication where compact size and multi-colour signalling are required.
