Universal E-Paper Raw Panel Driver Shield (B) For Arduino,MX25R6435F Chip

Universal E-Paper Driver Shield (B) for Arduino: Seamless E-Ink Panel Integration for Custom Display Applications

The Universal E-Paper Raw Panel Driver Shield (B) is a versatile controller board designed for Arduino-compatible platforms, allowing seamless interfacing with various E-Ink raw panels. Equipped with the MX25R6435F 64M-bit NOR Flash memory chip, this driver shield supports image storage and fast data access essential for driving high-resolution E-Ink displays. The board provides multiple connectivity headers and onboard voltage regulation, ensuring a stable power supply and compatibility across 3.3V and 5V Arduino boards. Whether you are prototyping an e-paper-based IoT display, shelf label, or low-power signage, this shield simplifies development and reduces time-to-market. Its onboard level shifters and flexible pinout also support a range of Waveshare E-Ink displays.

Key Features of the E-Paper Raw Panel Driver Shield (B)

• Compatible with Arduino and MCU Boards
  Works with most Arduino form-factor boards with support for both 3.3V and 5V logic.

• Supports Multiple E-Paper Panels
  Interfaces with Waveshare raw panel series from 1.54 to 7.5 inch E-Ink displays.

• MX25R6435F NOR Flash Chip
  Onboard 64M-bit flash for storing images and waveforms for faster screen refresh.

• Stable Power Supply & Voltage Regulation
  Integrated LDO regulators provide reliable power for low-power applications.

• Flexible Pin Mapping & SPI Interface
  SPI-based communication with flexible signal routing for customized setups.

• Compact & Easy to Integrate
  Small shield footprint ideal for embedded display projects and product prototypes.

Package Content:

1. e-Paper Shield (B) x1
2. e-Paper Adapter with 24PIN FFC cable ~200mm x1

Resources:

Universal E-Paper Driver Shield (B)

Supports host boards like nRF528xx/Arduino/NUCLEO, etc.

can be used to drive various SPI interface e-Paper from Waveshare

Pin Definition

What's On Board
