Technical Specifications
Brand:
TwoTrees
Material:
Aluminum + Stainless Steel + Injection Molding
Machine Dimensions:
745mmx660mmx473mm (29.33inx25.98inx18.62in)
Compatible Engraving Materials:
Plywood, MDF, Solid Wood, Acrylic, Carbon Fiber, Aluminum, Copper, Stainless Steel
Control Board Input Voltage:
24V
Display Size:
3.5-inch
Touch Screen:
3.5-inch IPS capacitive touch color screen (480*320 resolution)
Resolution:
480x320
Maximum Engraving Speed:
3000mm/min
Spindle Speed:
8000-30000 RPM depending on installation
Working Range:
460mmx460mmx100mm (18.11inx18.11inx3.94in)
Packaging Dimensions:
685x610x190mm
Maximum Power Consumption:
80W
Maximum Acceleration:
500mm/s2
Control Box Dimensions:
300mmx137mmx131mm (11.81inx5.39inx5.16in)
Supported Tool Diameter:
0.5mm to 7mm (ER11 Collet)
Power Supply:
216W Dual-Channel Switching Power Supply
Standby Power Consumption:
12.6W
Optimal Engraving Temperature:
0 to 40 C
Net Weight:
19Kg
Gross Weight:
24.2Kg
X/Y Axis Positioning Accuracy:
0.01mm
Z Axis Positioning Accuracy:
0.025mm
Engraving Accuracy:
100+-0.05mm
Spindle Motor:
500W (standard)
Tool Size:
Supports tools with diameters from 0.5mm to 7mm, depending on the inner bore of the ER11 collet
Engraving Layer Height:
0.1mm-20mm for non-metals & 0.1mm-0.2mm for metals
Programming Software:
VCarve, Fusion360, EASEL, Carveco Maker, FlatCAM,Camlab, Millmage, Carbide3D, and all Vectric software.
Supported Systems:
macOS, Windows, and Linux
Supported Program Formats:
.nc and .Gcode
Safety Certifications:
CE-EMC/CE-LVD/CE-MD/CE-RED/ROHS/FCC-Sdoc/FCC-ID
Warranty Information
All the products supplied by Evelta are genuine and original. Please note that this product is non-returnable. It includes a 1-year supplier warranty from the date of delivery, covering manufacturing defects only. In the event of any manufacturing defects or issues, we will replace the defective part upon confirmation by our technical team. Refunds or full product replacements are not offered.
