TPS62060DSGR - Switching Voltage Regulators 1.6A Step-Down Converter IC WSON-8-EP

Texas Instruments

No reviews yet Write a Review
SKU:
035-TPS62060DSGR
MPN:
TPS62060DSGR
Full Reel:
3000 (order in multiples of this to receive standard manufacturer packaging)
TPS62060DSGR 1.6A 3MHz Synchronous Step-Down Buck Switching Regulator IC WSON-8-EP Package
Quantity
Unit Price (ex. GST)
1 - 9
₹ 187.92
10 - 99
₹ 169.13
100 - 999
₹ 159.73
1000 or above
₹ 150.34
The TPS62060DSGR is a 2.7V–6V, 1.6A synchronous buck converter with 3MHz switching frequency, Power Save Mode, low ripple PWM operation, and <1µA shutdown current in a compact 8-pin WSON PowerPAD package. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹221.75 inc. GST
₹187.92 ex. GST

Technical Specifications

Brand:
Texas Instruments
Case/Package:
WSON-8-EP(2x2)
Number Of Pins:
8
Efficiency:
97 %
Max Input Voltage:
6 V
Max Operating Temperature:
85 C
Max Output Current:
1.6 A
Max Output Voltage:
6 V
Min Input Voltage:
2.7 V
Min Operating Temperature:
-40 C
Min Output Voltage:
800 mV
Min Supply Voltage:
2.7 V
Nominal Supply Current:
18 uA
Number of Outputs:
1
Output Current:
1.6 A
Output Voltage:
6 V
Switching Frequency:
3 MHz
Full Reel Quantity:
3000

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:

Datasheet

TPS62060DSGR – 1.6A, 3MHz High-Efficiency Synchronous Step-Down Converter IC

The TPS62060DSGR is a compact, high-efficiency 1.6A synchronous step-down (buck) DC-DC converter designed for low-voltage power regulation in portable, battery-powered, and embedded systems. Operating with an input voltage range of 2.7V to 6V, this converter is ideal for use with single-cell Li-Ion batteries, 3.3V, and 5V system supply rails. With a fixed 3MHz switching frequency, the device enables the use of ultra-small inductors and capacitors, providing a highly compact and cost-effective power solution. The TPS62060 integrates a power save mode (PSM) for high efficiency at light-load conditions and features an optimized control loop for low output voltage ripple. For low-noise applications, the converter can be configured into fixed-frequency PWM mode by pulling the MODE pin high. In shutdown mode, current consumption drops to less than 1uA, and an internal discharge circuit ensures the output capacitor safely discharges to ground. Optimized for minimal external components, the device operates seamlessly with a 1uH inductor and 10uF output capacitor, ensuring fast transient response and excellent voltage regulation. Built to perform reliably across a –40 C to +85 C temperature range, the TPS62060DSGR comes in a tiny 2mmx2mmx0.75mm 8-pin WSON PowerPAD package, offering superior thermal performance and efficient PCB utilization.

Key Features

  • Wide Input Voltage Range: 2.7V to 6V, ideal for Li-Ion battery and low-voltage systems.
  • 1.6A Continuous Output Current: Supports medium-power applications efficiently.
  • Fixed 3MHz Switching Frequency: Enables the use of small passive components and compact layouts.
  • High Efficiency Across Load Range: Power Save Mode maintains superior efficiency at light loads.
  • Low Output Voltage Ripple: Optimized PSM ensures clean, stable output for sensitive circuits.
  • Selectable Operating Mode: Fixed-frequency PWM operation available for low-noise applications.
  • Ultra-Low Shutdown Current: <1uA with automatic output capacitor discharge.
  • Compact Design: Works with 1µH inductors and 10µF capacitors for space-saving designs.
  • Robust Thermal Design: Operates across –40 C to+85 C in a thermally enhanced WSON PowerPAD package.
  • Tiny Footprint: 2mmx2mmx0.75mm WSON-8-EP package ideal for portable electronics.
