Technical Specifications
Brand:
Texas Instruments
Case/Package:
SOT-23
Mount:
Surface Mount
Number of Pins:
5
Ambient Temperature Range High:
85 C
Max Operating Temperature:
85 C
Max Power Dissipation:
437 mW
Max Reset Threshold Voltage:
3 V
Max Supply Current:
25 uA
Max Supply Voltage:
5.5 V
Min Operating Temperature:
-40 C
Min Reset Threshold Voltage:
2.86 V
Min Supply Voltage:
1.1 V
Nominal Supply Current:
15 uA
Number of Channels:
1
Number of Elements:
1
Number of Outputs:
1
Number of Voltages Monitored:
1
Output Current:
-400 uA
Overvoltage Threshold:
3 V
Packaging:
Cut Tape
Power Dissipation:
437 mW
Quiescent Current:
15 uA
Reset:
Active Low
Reset Timeout:
200 ms
Threshold Voltage:
2.93 V
Type:
Simple Reset/Power-On Reset
Undervoltage Threshold:
2.93 V
Watchdog Timer:
Yes
Height:
1.45 mm
Length:
2.9 mm
Thickness:
1.2 mm
Width:
1.6 mm
