TLA2528IRTER - 12 Bit Analog to Digital Converter 8 Input 1 SAR IC WQFN-16

Resources:

Datasheet

12-Bit 8-Channel SAR Analog-to-Digital Converter with Configurable Analog and Digital I/O

The TLA2528IRTER is a flexible 12-bit analog-to-digital converter designed for multi-sensor data acquisition and mixed-signal embedded systems. Developed by Texas Instruments, this device features eight multiplexed channels that can be independently configured as analog inputs, digital inputs, or digital outputs. This unique capability allows designers to combine ADC functionality with general-purpose I/O expansion in compact embedded designs.

The converter uses a high-performance SAR architecture and communicates through an I2C-compatible interface supporting speeds up to 3.4 MHz. An integrated internal oscillator manages ADC conversions, simplifying system design by eliminating the need for an external clock. With selectable I2C addresses and a compact WQFN-16 package, the TLA2528 is well suited for sensor monitoring, industrial control systems, portable instruments, and IoT devices that require flexible analog and digital interfacing.

Key Features

• 12-Bit Resolution SAR ADC – Provides accurate and reliable analog signal conversion.
• 8 Multiplexed Channels – Each channel configurable as analog input, digital input, or digital output.
• I2C-Compatible Interface – Supports communication speeds up to 3.4 MHz.
• Selectable I2C Addresses – Up to eight device addresses configurable via the ADDR pin.
• Integrated Internal Oscillator – Eliminates the need for an external conversion clock.
• Flexible Mixed-Signal Functionality – Combines ADC and digital I/O expansion in one device.
• Low-Power Operation – Suitable for portable and battery-powered applications.
• Compact WQFN-16 Package – Ideal for space-constrained embedded designs.
